GR
74HC373TS20ARCQ
D Latch 2V~6V 8 TSSOP-20 Latches
TSSOP-20RoHSActive
Octal Transparent D-Type Latches with 3-State Outputs
Datasheet (PDF)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,055 in stock
#C41414570
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹19.95 | ₹99.75 |
| 50+ | ₹15.66 | ₹783.00 |
| 150+ | ₹13.84 | ₹2,076.00 |
| 500+ | ₹11.55 | ₹5,775.00 |
| 3,000+ | ₹10.52 | ₹31,560.00 |
| 6,000+ | ₹9.91 | ₹59,460.00 |
5 × ₹19.95
₹99.75
excl. GST
₹117.71 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
74HC373TS20ARCQ
₹99.75 for 5 + GST
Specifications
- Quiescent Current
- 10uA
- Logic Type
- D Latch
- Series
- 74HC
- Voltage - Supply
- 2V~6V
- Operating Temperature
- -40℃~+85℃
- Output Type
- Tri-State
- Number of Gates
- 8
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.217 g
Overview
The 74HC373 consists of eight D-type transparent latches with 3-state outputs. This 8-BIT D-Type latches is controlled by a latch enable input (LE) and output enable input (OE ). While the LE input is held at a high level, the Q outputs will follow the data input. When the LE is taken low, the Q outputs will be latched at the logic level of D input data.
Key features
- 3-State Outputs
- Wide operating voltage range VCC = 2V to 6V
- Wide operating temperature range of -40°C to 85°C
- Low Input Current: 1 µA max
