74LVC11PW-TP

Schmitt trigger 1.65V~3.6V 7.5ns@3.6V,15pF TSSOP-14 Gates and Inverters

TSSOP-14RoHSActive

Manufacturer: TECH PUBLIC
Manufacturer part #: 74LVC11PW-TP
Store part #: C54561844
Package / case: TSSOP-14
Category: Gates and Inverters
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

2,435 in stock

#C54561844

Stock & price checked 28 h ago

Quantity	Unit price	Pack price
5+	₹32.98	₹164.90
50+	₹25.80	₹1,290.00
150+	₹22.72	₹3,408.00
500+	₹18.87	₹9,435.00
2,500+	₹17.16	₹42,900.00
5,000+	₹16.13	₹80,650.00

Quantity (min 5, multiples of 5)

5 × ₹32.98

₹164.90

excl. GST

₹194.58 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 2,500 per reel

74LVC11PW-TP

₹164.90 for 5 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Input Type: Schmitt trigger
Logic Family: 74LVC
Input Logic Level - Low: 120mV;700mV;800mV
Operating Temperature: -40℃~+125℃
Input Logic Level - High: 1.08V;1.7V;2V
Output Logic Level - High: 1.2V;1.9V;2.2V;2.4V;2.8V
Voltage - Supply: 1.65V~3.6V
Number of Channels: 3;3
Propagation Delay: 7.5ns@3.6V,15pF
Output Logic Level - Low: 100mV;450mV;300mV;400mV;550mV

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Moisture sensitivity: MSL 1 (unlimited)
Packaging: Tape & Reel (TR)
Standard pack: 2,500 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.184 g

Overview

This device provides three 3-input AND gate functions. The inputs can be driven by 3.0 V or 3.6 V devices. This feature allows these devices to be used as translators in mixed 3.0 V and 3.6 V environments. Schmitt-trigger action on all inputs enables the circuit to tolerate slower input rise and fall times. This device is fully specified for partial-power-down applications using IOFF. The IOFF circuit disables the outputs, preventing damaging reverse-current flow through the device when it is powered down.

Key features

Wide supply voltage range: 1.2 V ~ 3.6 V
CMOS low power consumption
Overvoltage-tolerant inputs up to 5.5 V
Latch-up performance exceeds 250 mA
Direct TTL-level interface capability
ESD protection: HBM ANSI/ESDA/JEDEC JS-00 Class 3A exceeds 6000 V, CDM ANSI/ESDA/JEDEC JS-002 Class C3 exceeds 2000 V
I<sub>OFF</sub> circuitry enables partial power-down mode operation
JEDEC standards compliant: JESD8-7 (1.65 V ~ 1.95 V), JESD8-5 (2.3 V ~ 2.7 V), JESD8C (2.7 V ~ 3.6 V)
Package: TSSOP-14
