UMW
XC6206P332MRLinear Voltage Regulator IC Positive Fixed 1 Output 250mA SOT-23
From
₹2.53
18,64,000 in stock
YONGYUTAIDatasheet (PDF)
AMS1117-1.2
1.2V Positive Fixed SOT-223 Voltage Regulators - Linear, Low Drop Out (LDO) Regulators
SOT-223RoHSActive
LDO High Voltage Regulator
- Manufacturer
- YONGYUTAI
- Manufacturer part #
- AMS1117-1.2
- Store part #
- C41417491
- Package / case
- SOT-223
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,350 in stock
#C41417491
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹7.47 | ₹74.70 |
| 100+ | ₹5.91 | ₹591.00 |
| 300+ | ₹5.13 | ₹1,539.00 |
| 2,500+ | ₹4.54 | ₹11,350.00 |
| 5,000+ | ₹4.07 | ₹20,350.00 |
| 10,000+ | ₹3.84 | ₹38,400.00 |
10 × ₹7.47
₹74.70
excl. GST
₹88.15 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
AMS1117-1.2
₹74.70 for 10 + GST
Specifications
- Output Voltage
- 1.2V
- Number of Outputs
- 1
- Operating Temperature
- -40℃~+125℃@(Tj)
- Supply Current (Iq)
- 5mA
- Output Configuration
- Positive
- Operating Voltage
- 12V
- Output Current
- 1A
- Features
- Over Current Protection;Thermal shutdown
- Output Type
- Fixed
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Moisture sensitivity
- MSL 3 (168 hours)
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.221 g
Overview
The AMS1117 is a three-terminal output current up to 1A Output low pressure difference linear regulator, 1.2V, 1.8V, 2.5V, 3.3V, 5.0V and adjustable output voltage and other versions, Its voltage drop is only 1.2V at 1A. With its excellent nature Energy and extreme economic performance, suitable for all kinds of electrical production Product.
Applications
- Palm pilots and laptops
- Battery chargers
- SCSI-II Active terminal
- mobile telephone
- Battery supply system
- Switching power supply rear voltage regulator
Key features
- The voltage drop of 1A output current is 1.2V
- Current limiting function
- Overheat protection
- Fixed output voltage 1.2V, 1.8V, 2.5V, 3.3V, 5.0V and adjustable output voltage version
- The voltage accuracy is 2% with a fixed output voltage of 1.2V
- Fixed output voltage 1.8V, 2.5V, 3.3V, 5.0V And adjustable output voltage accuracy is 1.5%
- Temperature range: -40 °C to +125 °C
