TWGMCDatasheet (PDF)
AMS1117-3.3(SOT-89)
Linear Voltage Regulator IC Positive Fixed 1 Output 1A SOT-89
SOT-89ROHS CompliantActive
1A Low Dropout Voltage Regulator
- Manufacturer
- TWGMC
- Manufacturer part #
- AMS1117-3.3(SOT-89)
- Store part #
- C47283698
- Package / case
- SOT-89
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,120 in stock
#C47283698
Stock & price checked 30 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹6.32 | ₹63.20 |
| 100+ | ₹5.03 | ₹503.00 |
| 300+ | ₹4.39 | ₹1,317.00 |
| 1,000+ | ₹3.90 | ₹3,900.00 |
| 5,000+ | ₹3.41 | ₹17,050.00 |
| 10,000+ | ₹3.21 | ₹32,100.00 |
10 × ₹6.32
₹63.20
excl. GST
₹74.58 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 1,000 per reel
AMS1117-3.3(SOT-89)
₹63.20 for 10 + GST
Specifications
- Output Voltage
- 3.3V
- Number of Outputs
- 1
- Operating Temperature
- -40℃~+125℃@(Tj)
- Supply Current (Iq)
- 5mA
- Output Configuration
- Positive
- Operating Voltage
- 18V
- Output Current
- 1A
- Features
- Thermal shutdown
- Output Type
- Fixed
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- Packaging
- Tape & Reel (TR)
- Standard pack
- 1,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.135 g
Overview
The AMS1117 series is a family of low-dropout voltage regulators capable of supplying up to 1A of output current. The series offers six fixed output voltages: 1.2V, 1.5V, 1.8V, 2.5V, 3.3V, and 5.0V, as well as an adjustable version. On-chip precision trimming adjusts the reference/output voltage to within ±2% accuracy. On-chip thermal limiting provides protection against excessive junction temperatures resulting from any combination of overload and ambient temperature conditions. The series is available in SOT-223, TO-252, and SOT89 packages. A minimum 10μF tantalum capacitor on the output is required to improve transient response and ensure stability.
Applications
- Post-regulator for switching DC/DC converters
- High-efficiency linear regulator
- Battery charger
- PC add-in card
- Motherboard clock supply
- LCD monitor
- Set-top box
Key features
- Low dropout voltage
- Load regulation: 0.5% max
- Optimized for low-voltage applications
- On-chip thermal limiting
- Maximum input voltage: 18V
- Adjustable output or fixed 1.2V, 1.5V, 1.8V, 2.5V, 3.3V, 5V
- Standard SOT-223, TO-252, SOT89 packages
