VikingDatasheet (PDF)
AR03BTCX6801A010
6.8kΩ 100mW 50V Thin Film Resistor ±25ppm/℃ ±0.1% 0603 Chip Resistor - Surface Mount RoHS
0603ROHS CompliantActive
RES 6.8kΩ ±0.1% 100mW 0603
- Manufacturer
- Viking
- Manufacturer part #
- AR03BTCX6801A010
- Store part #
- C374530
- Package / case
- 0603
- Category
- Chip Resistor - Surface Mount
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
3,540 in stock
#C374530
Stock & price checked 4 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 20+ | ₹3.63 | ₹72.60 |
| 200+ | ₹2.79 | ₹558.00 |
| 600+ | ₹2.32 | ₹1,392.00 |
| 5,000+ | ₹2.04 | ₹10,200.00 |
| 10,000+ | ₹1.80 | ₹18,000.00 |
| 20,000+ | ₹1.67 | ₹33,400.00 |
20 × ₹3.63
₹72.60
excl. GST
₹85.67 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 5,000 per reel
AR03BTCX6801A010
₹72.60 for 20 + GST
Specifications
- Resistance
- 6.8kΩ
- Power(Watts)
- 100mW
- Voltage Rating
- 50V
- Operating Temperature
- -55℃~+155℃
- Type
- Thin Film Resistor
- Temperature Coefficient
- ±25ppm/℃
- Tolerance
- ±0.1%
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 5,000 / Reel
- Sold per
- Piece
- Minimum order
- 20 (multiples of 20)
- Unit weight
- 0.023 g
Overview
Applications
- Automotive, medical devices, test/measurement equipment, printing equipment, automated equipment controllers
Key features
- AEC-Q200 compliant
- Advanced thin-film technology
- RoHS compliant
- Special materials, design, and processes for high-sulfur applications
- Tested for humidity resistance, moisture resistance, and anti-sulfur capability
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | ARG03BTC6801#C2941290Viking · 0603 | Viking | 0603 | 5,000 | ₹3.33 · 5,000 in stock | View |
 | AR03BTCX6801#C318134Viking · 0603 | Viking | 0603 | 1,240 | ₹4.51 · 1,240 in stock | View |
| AR03BTCX6801A#C5568699Viking · 0603 | Viking | 0603 | On request | Price on request | Quote | |
