AT24C32CDR165

32Kbit 1MHz I2C SOP-8 Memory

SOP-8RoHSActive

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

2,500 in stock

#C51026297

Stock & price checked 2 days ago

Quantity (min 10, multiples of 10)

10 × ₹8.64

₹86.40

excl. GST

₹101.95 incl. 18% GST

AT24C32CDR165

₹86.40 for 10 + GST

Specifications

Operating Temperature: -40℃~+85℃
Features: Noise suppression function;Hardware write protection function;Page write protection function
Memory Size: 32Kbit
Voltage - Supply: 1.8V~5.5V;1.6mA
Clock Frequency: 1MHz
Access Time: 0.9us;0.55us
Data Retention - TDR (Year): 100 Years
Write Cycle Time(tWC): 5ms
Standby Supply Current: 10uA
Write Cycle Endurance: 1 million cycles
Interface: I2C

Single supply voltage, high-speed operation, minimum operating voltage down to 1.7V
1 MHz clock frequency support from 2.5V to 5.5V
400kHz clock frequency support from 1.7V to 2.5V
Low-power CMOS technology
Maximum read current 400μA
Maximum write current 1.6mA
Schmitt trigger inputs with filtering for noise suppression
Sequential and random read capability
32-byte page write mode with partial page write support
Write protection for entire memory array
Additional writeable lockable page
Additional 128-bit serial number
Self-timed write cycle (5ms max)
High reliability
ESD (Human Body Model): 6KV
Endurance: 1 million write cycles
Data retention: 100 years
Latch-up immunity: +/- 200mA
Packages: PDIP, SOP, TSSOP, DFN, SOT23-5, and WLCSP
