GREENMICRODatasheet (PDF)
AT24C32CP165
32Kbit 1MHz I2C DIP-8 Memory
DIP-8RoHSActive
- Manufacturer
- GREENMICRO
- Manufacturer part #
- AT24C32CP165
- Store part #
- C51026308
- Package / case
- DIP-8
- Category
- Memory
- Packaging
- Tube-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,970 in stock
#C51026308
Stock & price checked 28 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹12.90 | ₹64.50 |
| 50+ | ₹10.11 | ₹505.50 |
| 150+ | ₹8.71 | ₹1,306.50 |
| 500+ | ₹7.66 | ₹3,830.00 |
| 2,000+ | ₹6.83 | ₹13,660.00 |
| 4,000+ | ₹6.40 | ₹25,600.00 |
5 × ₹12.90
₹64.50
excl. GST
₹76.11 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 50 per tube
AT24C32CP165
₹64.50 for 5 + GST
Specifications
- Operating Temperature
- -40℃~+85℃
- Features
- Hardware write protection function;Noise suppression function
- Memory Size
- 32Kbit
- Voltage - Supply
- 1.8V~5.5V;1.6mA
- Clock Frequency
- 1MHz
- Access Time
- 0.9us
- Data Retention - TDR (Year)
- 100 Years
- Write Cycle Time(tWC)
- 5ms
- Standby Supply Current
- 10uA
- Write Cycle Endurance
- 1 million cycles
- Interface
- I2C
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Moisture sensitivity
- MSL 3 (168 hours)
- Packaging
- Tube-packed
- Standard pack
- 50 / Tube
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.945 g
Overview
Key features
- Single supply voltage, high-speed operation, minimum operating voltage down to 1.7V
- 1 MHz clock frequency support from 2.5V to 5.5V
- 400kHz clock frequency support from 1.7V to 2.5V
- Low-power CMOS technology
- Maximum read current 400μA
- Maximum write current 1.6mA
- Schmitt trigger inputs with filtering for noise suppression
- Sequential and random read capability
- 32-byte page write mode with partial page write support
- Write protection for entire memory array
- Additional writeable lockable page
- Additional 128-bit serial number
- Self-timed write cycle (5ms max)
- High reliability
- ESD (Human Body Model): 6KV
- Endurance: 1 million write cycles
- Data retention: 100 years
- Latch-up immunity: +/- 200mA
- Packages: PDIP, SOP, TSSOP, DFN, SOT23-5, and WLCSP
