DIODESDatasheet (PDF)
AZ1117H-ADJTRG1
1.2V Positive Adjustable SOT-223 Voltage Regulators - Linear, Low Drop Out (LDO) Regulators RoHS
SOT-223ROHS CompliantActive
Low Dropout Linear Regulator
- Manufacturer
- DIODES
- Manufacturer part #
- AZ1117H-ADJTRG1
- Store part #
- C110475
- Package / case
- SOT-223
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
58,265 in stock
#C110475
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹12.41 | ₹62.05 |
| 50+ | ₹9.90 | ₹495.00 |
| 150+ | ₹8.65 | ₹1,297.50 |
| 500+ | ₹7.70 | ₹3,850.00 |
| 2,500+ | ₹6.25 | ₹15,625.00 |
| 4,000+ | ₹5.87 | ₹23,480.00 |
5 × ₹12.41
₹62.05
excl. GST
₹73.22 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 4,000 per reel
AZ1117H-ADJTRG1
₹62.05 for 5 + GST
Specifications
- Output Voltage
- 1.2V
- Number of Outputs
- 1
- Operating Temperature
- -20℃~+125℃@(Tj)
- Output Configuration
- Positive
- Operating Voltage
- 15V
- Output Current
- 1A
- Features
- Over Current Protection;Thermal shutdown
- Output Type
- Adjustable
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 4,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.232 g
Overview
The AZ1117 is a low dropout three-terminal regulator. The AZ1117 has been optimized for low voltage where transient response and minimum input voltage are critical. It provides current limit and thermal shutdown. Its circuit includes a trimmed bandgap reference to assure output voltage accuracy to be within ±1%. Onchip thermal shutdown provides protection against a combination of high current and ambient temperature that would create excessive junction temperature. The AZ1117 is available in 1.2V, 1.5V, 1.8V, 2.5V, 3.3V, 5.0V fixed output voltage versions and ADJ output voltage version. The fixed versions integrate the adjust resistors. It is also available in an adjustable version which can set the output voltage with two external resistors. The AZ1117 is available in the industry-standard SOT-223 and SOT89 power packages.
Applications
- USB Device
- Add-on Card
- DVD Player
- PC Motherboard
Key features
- Current Limit: 1.0A (Typ.)
- Output Noise from 10Hz to 10KHz: 0.003% of VOUT
- PSRR at lour = 300mA and f = 120Hz: 70dB
- Output Voltage Accuracy: ±1%
- On-chip Thermal Shutdown
- Maximum Quiescent Current: lQMAX = 6mA
- Operation Junction Temperature: -20 to +125°C
