BL
BL24C08F-NTRC
8Kbit 1MHz I2C UDFN-8L(2x3) Memory
UDFN-8L(2x3)RoHSActive
8K-bit I²C Interface EEPROM
Datasheet (PDF)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
14,395 in stock
#C5185882
Stock & price checked 46 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹14.06 | ₹70.30 |
| 50+ | ₹11.29 | ₹564.50 |
| 150+ | ₹9.90 | ₹1,485.00 |
| 500+ | ₹8.86 | ₹4,430.00 |
| 3,000+ | ₹7.69 | ₹23,070.00 |
| 6,000+ | ₹7.26 | ₹43,560.00 |
5 × ₹14.06
₹70.30
excl. GST
₹82.95 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
BL24C08F-NTRC
₹70.30 for 5 + GST
Specifications
- Operating Temperature
- -40℃~+85℃
- Features
- Hardware write protection function;Noise suppression function
- Memory Size
- 8Kbit
- Voltage - Supply
- 1.7V~5.5V;0.28mA
- Clock Frequency
- 1MHz
- Access Time
- 0.9us;0.45us
- Data Retention - TDR (Year)
- 100 Years
- Write Cycle Time(tWC)
- 3ms
- Standby Supply Current
- 0.03uA
- Write Cycle Endurance
- 1,000,000 cycles
- Interface
- I2C
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Moisture sensitivity
- MSL 3 (168 hours)
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.048 g
Overview
The BL24C08F provides 8192 bits of serial electrically erasable and programmable read-only memory (EEPROM), organized as 1024 words of 8 bits each. The device is optimized for use in many industrial and commercial applications where low-power and low-voltage operation are essential.
Key features
- Compatible with all I²C bidirectional data transfer protocol
- Memory array: 8K bits (1024x8) of EEPROM
- Page size: 16 bytes
- Single supply voltage and high speed: 1 MHz
- Random and sequential Read modes
- Write: Byte Write within 3 ms, Page Write within 3 ms, Partial Page Writes Allowed
- Write Protect Pin for Hardware Data Protection
- Schmitt Trigger, Filtered Inputs for Noise Suppression
- High-reliability
- Endurance: 1 Million Write Cycles
- Data Retention: 100 Years
- Enhanced ESD/Latch-up protection
- HBM 5000V
- 8-lead PDIP/SOP/TSSOP/ UDFN/SOT23-5 and TSOT23-5 packages
