ROHMDatasheet (PDF)
BU33UA3WNVX-TL
3.3V Positive Fixed DFN-4-EP(1x1) Voltage Regulators - Linear, Low Drop Out (LDO) Regulators RoHS
DFN-4-EP(1x1)ROHS3 CompliantActive
CMOS LDO Regulator for Portable Equipments
- Manufacturer
- ROHM
- Manufacturer part #
- BU33UA3WNVX-TL
- Store part #
- C510081
- Package / case
- DFN-4-EP(1x1)
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
4,770 in stock
#C510081
Stock & price checked 23 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹32.45 | ₹162.25 |
| 50+ | ₹27.86 | ₹1,393.00 |
| 150+ | ₹25.89 | ₹3,883.50 |
| 500+ | ₹23.44 | ₹11,720.00 |
| 2,500+ | ₹22.35 | ₹55,875.00 |
| 5,000+ | ₹21.68 | ₹1,08,400.00 |
5 × ₹32.45
₹162.25
excl. GST
₹191.46 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 5,000 per reel
BU33UA3WNVX-TL
₹162.25 for 5 + GST
Specifications
- Output Voltage
- 3.3V
- Number of Outputs
- 1
- Operating Temperature
- -40℃~+85℃@(Ta)
- Supply Current (Iq)
- 50uA
- Output Configuration
- Positive
- Operating Voltage
- 5.5V
- Output Current
- 300mA
- Features
- Enable control;Output discharge;Over Current Protection;Short Circuit Protection;Thermal shutdown
- Output Type
- Fixed
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 5,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.021 g
Overview
BUxxUA3WNVX series is high-performance FULL CMOS regulator with 300-mA output, which is mounted on versatile package SSON004X1010 (1.00mm × 1.00mm × 0.60mm). It has excellent noise characteristics and load responsiveness characteristics despite its low circuit current consumption of 50μA. It is most appropriate for various applications such as power supplies for logic IC, RF, and camera modules.
Applications
- Battery-powered portable equipment
Key features
- High accuracy detection low current consumption
- Compatible with small ceramic capacitor (Cin = Co = 1.0uF)
- With built-in output discharge circuit
- High ripple rejection
- ON/OFF control of output voltage
- With built-in over current protection circuit and thermal shutdown circuit
- Low dropout voltage
