IsabellenhuetteDatasheet (PDF)
BVT-M-R0005-1.0
6W 0.5mΩ ±115ppm/℃ ±1% 2512 Chip Resistor - Surface Mount RoHS
2512ROHS3 CompliantActive
RES 0.5mΩ ±1% 6W 2512
- Manufacturer
- Isabellenhuette
- Manufacturer part #
- BVT-M-R0005-1.0
- Store part #
- C6869656
- Package / case
- 2512
- Category
- Chip Resistor - Surface Mount
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
865 in stock
#C6869656
Stock & price checked 3 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹114.06 | ₹114.06 |
| 10+ | ₹93.67 | ₹936.70 |
| 30+ | ₹83.48 | ₹2,504.40 |
| 100+ | ₹73.29 | ₹7,329.00 |
| 500+ | ₹67.22 | ₹33,610.00 |
| 1,000+ | ₹64.18 | ₹64,180.00 |
1 × ₹114.06
₹114.06
excl. GST
₹134.59 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 5,000 per reel
BVT-M-R0005-1.0
₹114.06 for 1 + GST
Specifications
- Power(Watts)
- 6W
- Resistance
- 0.5mΩ
- Temperature Coefficient
- ±115ppm/℃
- Tolerance
- ±1%
- Operating Temperature
- -65℃~+170℃
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 5,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.19 g
Overview
Applications
- Current sensors for power hybrid applications, automotive high-current applications, inverters, and power modules
Key features
- Rated power up to 6 W
- Continuous current load up to 100 A (0.3 mΩ)
- Heavy-duty copper terminations
- Excellent long-term stability
- Operating temperature range -65 to +170℃ due to special design
- RoHS 2011/65/EU compliant
- AEC-Q200 qualified
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | WSLF2512L5000FEA#C844703VISHAY · 2512 | VISHAY | 2512 | 5,048 | ₹84.50 · 5,048 in stock | View |
| Y14830R00050F9R#C6337402VISHAY · 2512 | VISHAY | 2512 | On request | Price on request | Quote | |
| CHSA2512R0005F#C5596121EATON · 2512 | EATON | 2512 | On request | ₹20.28 · 0 in stock | View | |
