BOURNSDatasheet (PDF)
CD214B-FS2K
35ns 800V 2.2V@2A 2A SMD Single Diodes RoHS
SMDROHS3 CompliantActive
- Manufacturer
- BOURNS
- Manufacturer part #
- CD214B-FS2K
- Store part #
- C17483550
- Package / case
- SMD
- Category
- Single Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
90 in stock
#C17483550
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹58.04 | ₹58.04 |
| 10+ | ₹56.97 | ₹569.70 |
| 30+ | ₹56.32 | ₹1,689.60 |
| 100+ | ₹55.67 | ₹5,567.00 |
1 × ₹58.04
₹58.04
excl. GST
₹68.49 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 5,000 per reel
CD214B-FS2K
₹58.04 for 1 + GST
Specifications
- Reverse Recovery Time (trr)
- 35ns
- Voltage - DC Reverse (Vr) (Max)
- 800V
- Operating Junction Temperature Range
- -65℃~+175℃
- Voltage - Forward(Vf@If)
- 2.2V@2A
- Reverse Leakage Current (Ir)
- 5uA@800V
- Current - Rectified
- 2A
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 5,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.111 g
Overview
Manufacturers of portable communications, computing, and video equipment are challenging the semiconductor industry to develop increasingly smaller electronic components. Bourns offers glass passivated rectifiers for rectification applications in a compact chip package compatible with the DO-214AA (SMB) size format. The glass passivated rectifier diodes provide 2A forward current with repetitive peak reverse voltage options ranging from 200V to 800V.
Applications
- Switching mode power supplies, portable device batteries, high-frequency rectification, DC/DC converters, telecommunications
Key features
- RoHS compliant*
- Low profile
- Low power loss, high efficiency
- UL 94V-0 rated
