VenkelDatasheet (PDF)
CR0603-10W-222JT
100mW 2.2kΩ Thick Film Resistor ±5% ±200ppm/℃ 0603 Chip Resistor - Surface Mount RoHS
0603ROHS3 CompliantActive
RES 2.2kΩ ±5% 100mW 0603
- Manufacturer
- Venkel
- Manufacturer part #
- CR0603-10W-222JT
- Store part #
- C4321506
- Package / case
- 0603
- Category
- Chip Resistor - Surface Mount
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
4,800 in stock
#C4321506
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 100+ | ₹0.344 | ₹34.40 |
| 1,000+ | ₹0.2646 | ₹264.60 |
| 5,000+ | ₹0.2249 | ₹1,124.50 |
| 10,000+ | ₹0.1985 | ₹1,985.00 |
| 50,000+ | ₹0.172 | ₹8,600.00 |
100 × ₹0.344
₹34.40
excl. GST
₹40.59 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 5,000 per reel
CR0603-10W-222JT
₹34.40 for 100 + GST
Specifications
- Power(Watts)
- 100mW
- Resistance
- 2.2kΩ
- Operating Temperature
- -55℃~+155℃
- Type
- Thick Film Resistor
- Tolerance
- ±5%
- Temperature Coefficient
- ±200ppm/℃
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 5,000 / Reel
- Sold per
- Piece
- Minimum order
- 100 (multiples of 100)
- Unit weight
- 0.038 g
Overview
Key features
- TCR as low as 100ppm
- Size range from 01005 to 2512
- Stable across temperature range
- Halogen-free
- Good power dissipation capability (conservatively rated power rating)
- 100% matte tin over nickel plating with wraparound termination, excellent solderability
- Select resistance values suitable for conductive epoxy applications (suitable for MRI applications)
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | CRCW06032K20JNEAC#C2076616VISHAY · 0603 | VISHAY | 0603 | 450 | ₹2.08 · 450 in stock | View |
 | RMCF0603JT2K20#C2479384SEI(Stackpole Electronics Inc.) · 0603 | SEI(Stackpole Electronics Inc.) | 0603 | 4,500 | ₹0.5557 · 4,500 in stock | View |
 | ERJ3GEYJ222V#C278639PANASONIC · 0603 | PANASONIC | 0603 | 8,200 | ₹0.860 · 8,200 in stock | View |
 | CRCW06032K20JNEA#C844151VISHAY · 0603 | VISHAY | 0603 | On request | ₹1.76 · 0 in stock | View |
 | ERJP03J222V#C427273PANASONIC · 0603 | PANASONIC | 0603 | 6,780 | ₹5.85 · 6,780 in stock | View |
