VenkelDatasheet (PDF)
CR0603-10W-3013FT
301kΩ ±1% 100mW 0603 Thick Film Resistor
0603ROHS3 CompliantActive
RES 301kΩ ±1% 100mW 0603
- Manufacturer
- Venkel
- Manufacturer part #
- CR0603-10W-3013FT
- Store part #
- C6537899
- Package / case
- 0603
- Category
- Chip Resistor - Surface Mount
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
4,700 in stock
#C6537899
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 100+ | ₹0.344 | ₹34.40 |
| 1,000+ | ₹0.2646 | ₹264.60 |
| 5,000+ | ₹0.2117 | ₹1,058.50 |
| 10,000+ | ₹0.1985 | ₹1,985.00 |
| 50,000+ | ₹0.172 | ₹8,600.00 |
100 × ₹0.344
₹34.40
excl. GST
₹40.59 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 5,000 per reel
CR0603-10W-3013FT
₹34.40 for 100 + GST
Specifications
- Power(Watts)
- 100mW
- Resistance
- 301kΩ
- Operating Temperature
- -55℃~+155℃
- Type
- Thick Film Resistor
- Temperature Coefficient
- ±100ppm/℃
- Tolerance
- ±1%
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 5,000 / Reel
- Sold per
- Piece
- Minimum order
- 100 (multiples of 100)
- Unit weight
- 0.038 g
Overview
Key features
- TCR as low as 100ppm
- Size range from 01005 to 2512
- Stable across temperature range
- Halogen-free
- Good power dissipation capability (conservatively rated power rating)
- 100% matte tin over nickel plating with wraparound termination, excellent solderability
- Select resistance values suitable for conductive epoxy applications (suitable for MRI applications)
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | RTT033013FTP#C103522RALEC · 0603 | RALEC | 0603 | 100 | ₹0.1455 · 100 in stock | View |
 | AC0603FR-07301KL#C227805YAGEO · 0603 | YAGEO | 0603 | 4,800 | ₹1.02 · 4,800 in stock | View |
 | 0603WAF3013T5E#C23026UNI-ROYAL · 0603 | UNI-ROYAL | 0603 | 34,400 | ₹0.2911 · 34,400 in stock | View |
 | RMCF0603FT301K#C2479485SEI(Stackpole Electronics Inc.) · 0603 | SEI(Stackpole Electronics Inc.) | 0603 | 3,300 | ₹0.5292 · 3,300 in stock | View |
 | RC0603FR-07301KL#C273742YAGEO · 0603 | YAGEO | 0603 | On request | ₹0.8203 · 0 in stock | View |
