CRCW120651R0FKEAHP
750mW 51Ω Thick Film Resistor ±100ppm/℃ ±1% 1206 Chip Resistor - Surface Mount RoHS
RES 51Ω ±1% 750mW 1206
- Manufacturer
- VISHAY
- Manufacturer part #
- CRCW120651R0FKEAHP
- Store part #
- C5578750
- Package / case
- 1206
- Category
- Chip Resistor - Surface Mount
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
5 in stock
#C5578750
Stock & price checked 12 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹10.04 | ₹50.20 |
| 50+ | ₹9.80 | ₹490.00 |
| 150+ | ₹9.64 | ₹1,446.00 |
| 500+ | ₹9.50 | ₹4,750.00 |
5 × ₹10.04
₹50.20
excl. GST
₹59.24 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 5,000 per reel
CRCW120651R0FKEAHP
₹50.20 for 5 + GST
Specifications
- Power(Watts)
- 750mW
- Resistance
- 51Ω
- Type
- Thick Film Resistor
- Temperature Coefficient
- ±100ppm/℃
- Tolerance
- ±1%
- Operating Temperature
- -55℃~+155℃
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 5,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.034 g
Overview
The production process is strictly controlled and follows an extensive set of instructions to ensure repeatability. Cermet film layers and glass cover layers are deposited on both sides of a high-grade (Al₂O₃) ceramic substrate, with prefabricated internal contacts on both sides of the substrate. A special laser is used to fine-trim the resistive layer to achieve the target resistance value without damaging the ceramic. The resistive element is covered by a protective coating for electrical, mechanical, and climatic protection. Terminations are finished with pure tin plating over nickel. Final production results are verified by an extensive test program performed on 100% of individual chip resistors. Only conforming products are placed directly into carrier tape in accordance with IEC 60286-3 Type 1a and Type 2a.
Applications
- Automotive, Industrial, Commercial, High Power
Key features
- Excellent pulse load capability
- Enhanced power rating
- Double-sided printed resistive element
- AEC-Q200 qualified
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
| CHP1206-FX-51R0ELF#C5573977BOURNS · 1206 | BOURNS | 1206 | On request | ₹24.25 · 0 in stock | View | |
| RPC1206FT51R0-UP#C5890443SEI(Stackpole Electronics Inc.) · 1206 | SEI(Stackpole Electronics Inc.) | 1206 | On request | ₹30.27 · 0 in stock | View | |
| WK73R2BTTD51R0D#C7149849KOA · SMD,3.2x1.6mm | KOA | SMD,3.2x1.6mm | On request | ₹33.91 · 0 in stock | View | |
| SG73P2BRTTD51R0F#C6677617KOA · 1206 | KOA | 1206 | On request | Price on request | Quote | |
| HRG3216P-51R0-D-T5#C1719972SUSUMU · 1206 | SUSUMU | 1206 | On request | ₹31.88 · 0 in stock | View | |
