Shenzhen DongKe SemiconDatasheet (PDF)
DK8120AP
1.6A 25kHz~110kHz 2W 700V 60V Flyback ESOP-7 AC DC Converters, Offline Switchers
ESOP-7RoHSActive
- Manufacturer
- Shenzhen DongKe Semicon
- Manufacturer part #
- DK8120AP
- Store part #
- C53183665
- Package / case
- ESOP-7
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
3,580 in stock
#C53183665
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹50.25 | ₹251.25 |
| 50+ | ₹39.78 | ₹1,989.00 |
| 150+ | ₹35.18 | ₹5,277.00 |
| 500+ | ₹29.74 | ₹14,870.00 |
| 2,500+ | ₹27.23 | ₹68,075.00 |
| 4,000+ | ₹25.55 | ₹1,02,200.00 |
5 × ₹50.25
₹251.25
excl. GST
₹296.47 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 4,000 per reel
DK8120AP
₹251.25 for 5 + GST
Specifications
- Output Current
- 1.6A
- Frequency - Switching
- 25kHz~110kHz
- Pd - Power Dissipation
- 2W
- Voltage - Breakdown
- 700V
- Voltage - Supply
- 60V
- Topology
- Flyback
- Features
- Constant Voltage (CV);Soft-start;Over Voltage Protection;Overtemperature protection (OTP);Over Current Protection;Under Voltage Protection
- Working Mode
- QR
- Feedback System
- Primary-side feedback
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 4,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.5 g
Overview
This series is an AC-DC power management power switch IC integrating a 700V GaN HEMT, featuring constant power functionality and operating in quasi-resonant mode to improve power system efficiency. The IC greatly simplifies the design and manufacturing of flyback AC-DC converters, making it especially suitable for applications requiring high conversion efficiency and high power density. It integrates comprehensive protection features, including VCC OVP/UVP, over-temperature protection, primary OCP, output OVP/UVP, VS pull-up resistor open protection, VS pull-down resistor short protection, and CS resistor short protection. This series is available in an ESOP-7 package.
Applications
- High power density fast chargers
- Adapters
- Laptop adapters
- Tablet adapters
- Set-top box adapters
Key features
- Maximum switching frequency limited to 110KHz
- Standby power consumption below 50mW
- Constant power control capability
- Quasi-resonant operation mode
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | DK8125AP#C53183666Shenzhen DongKe Semicon · ESOP-7 | Shenzhen DongKe Semicon | ESOP-7 | 3,714 | ₹55.12 · 3,714 in stock | View |
 | DK8135AP#C53183667Shenzhen DongKe Semicon · ESOP-7 | Shenzhen DongKe Semicon | ESOP-7 | 80 | ₹78.10 · 80 in stock | View |
| DK8120#C53183671Shenzhen DongKe Semicon · ESOP-7 | Shenzhen DongKe Semicon | ESOP-7 | 470 | ₹26.67 · 470 in stock | View | |
 | DK8020AP#C50083751Shenzhen DongKe Semicon · ESOP-7 | Shenzhen DongKe Semicon | ESOP-7 | 855 | ₹50.53 · 855 in stock | View |
 | DK8025AP#C53183664Shenzhen DongKe Semicon · ESOP-7 | Shenzhen DongKe Semicon | ESOP-7 | 424 | ₹55.70 · 424 in stock | View |
