DIODESDatasheet (PDF)
DMS2220LFDB-7
20V 1 Independent 520mV@1A 1A UDFN2020-6 Single FETs, MOSFETs RoHS
UDFN2020-6ROHS CompliantSold out at source
Super Barrier Rectifier
- Manufacturer
- DIODES
- Manufacturer part #
- DMS2220LFDB-7
- Store part #
- C5245499
- Package / case
- UDFN2020-6
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
50 in stock
#C5245499
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹24.16 | ₹120.80 |
| 50+ | ₹23.83 | ₹1,191.50 |
| 150+ | ₹23.62 | ₹3,543.00 |
| 500+ | ₹23.39 | ₹11,695.00 |
5 × ₹24.16
₹120.80
excl. GST
₹142.54 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
DMS2220LFDB-7
₹120.80 for 5 + GST
Specifications
- Reverse Leakage Current (Ir)
- 100uA@20V
- Operating Junction Temperature Range
- -55℃~+150℃
- Voltage - DC Reverse(Vr)
- 20V
- Non-Repetitive Peak Forward Surge Current
- 3A
- Diode Configuration
- 1 Independent
- Voltage - Forward(Vf@If)
- 520mV@1A
- Current - Rectified
- 1A
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Sold out at source
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.02 g
Overview
Key features
- Low on-resistance: 95mΩ at VGS = -4.5V, 120mΩ at VGS = -2.5V, 86mΩ typical at VGS = -1.8V
- Low gate threshold voltage, -1.3V max
- Fast switching speed
- Low input/output leakage
- Integrated low Vr Super Barrier Rectifier (SBR)
- Low profile, 0.5mm max height
- Fully lead-free and fully RoHS compliant
- Halogen- and antimony-free, "Green" device
- AEC-Q101 qualified with high reliability
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | DMS2220LFDB-7#C3277051DIODES · UDFN2020-6 | DIODES | UDFN2020-6 | 80 | ₹15.04 · 80 in stock | View |
