PANASONICDatasheet (PDF)
ERA-2AEB6341X
63mW 6.34kΩ Thin Film Resistor ±25ppm/℃ ±0.1% 0402 Chip Resistor - Surface Mount RoHS
0402ROHS3 CompliantActive
RES 6340Ω ±0.1% 0.063W 0402
- Manufacturer
- PANASONIC
- Manufacturer part #
- ERA-2AEB6341X
- Store part #
- C4332793
- Package / case
- 0402
- Category
- Chip Resistor - Surface Mount
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
25 in stock
#C4332793
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹21.92 | ₹109.60 |
| 50+ | ₹17.36 | ₹868.00 |
| 150+ | ₹15.39 | ₹2,308.50 |
| 500+ | ₹12.95 | ₹6,475.00 |
| 2,500+ | ₹11.85 | ₹29,625.00 |
| 5,000+ | ₹11.21 | ₹56,050.00 |
5 × ₹21.92
₹109.60
excl. GST
₹129.33 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 10,000 per reel
ERA-2AEB6341X
₹109.60 for 5 + GST
Specifications
- Power(Watts)
- 63mW
- Resistance
- 6.34kΩ
- Operating Temperature
- -55℃~+155℃
- Type
- Thin Film Resistor
- Temperature Coefficient
- ±25ppm/℃
- Tolerance
- ±0.1%
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 10,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.026 g
Overview
Key features
- High reliability: stable performance in high-temperature and high-humidity environments (85°C, 65% RH rated load, operating temperature range: -55°C ~ +155°C)
- High accuracy: low resistance tolerance and TCR
- High performance: low current noise, excellent linearity
- Reference standards: IEC 60115-8, JIS C 5201-8, JEITA RC-2133C
- AEC-Q200 compliant (except ERA1A)
- RoHS compliant
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
| RP73PF1E6K34BTDF#C2145665TE Connectivity · 0402 | TE Connectivity | 0402 | On request | Price on request | Quote | |
| RN73R1ETTP6341B25#C2517867KOA · 0402 | KOA | 0402 | On request | Price on request | Quote | |
| CPF0402B6K34E1#C4049130TE Connectivity · 0402 | TE Connectivity | 0402 | On request | Price on request | Quote | |
| CPF0402B6K34E#C4189849TE Connectivity · 0402 | TE Connectivity | 0402 | On request | Price on request | Quote | |
| RNCF0402BKE6K34#C4287737SEI(Stackpole Electronics Inc.) · 0402 | SEI(Stackpole Electronics Inc.) | 0402 | On request | Price on request | Quote | |
