PANASONICDatasheet (PDF)
ERA-2AED153X
15kΩ ±0.5% 63mW 0402 Thin Film Resistor AEC-Q200
0402ROHS3 CompliantActive
RES 15kΩ ±0.5% 63mW 0402
- Manufacturer
- PANASONIC
- Manufacturer part #
- ERA-2AED153X
- Store part #
- C4035453
- Package / case
- 0402
- Category
- Chip Resistor - Surface Mount
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
190 in stock
#C4035453
Stock & price checked 4 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹12.50 | ₹62.50 |
| 50+ | ₹10.00 | ₹500.00 |
| 150+ | ₹8.76 | ₹1,314.00 |
| 500+ | ₹7.82 | ₹3,910.00 |
| 2,500+ | ₹7.06 | ₹17,650.00 |
| 5,000+ | ₹6.69 | ₹33,450.00 |
5 × ₹12.50
₹62.50
excl. GST
₹73.75 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 10,000 per reel
ERA-2AED153X
₹62.50 for 5 + GST
Specifications
- Resistance
- 15kΩ
- Power(Watts)
- 63mW
- Voltage Rating
- 50V
- Operating Temperature
- -55℃~+155℃
- Type
- Thin Film Resistor
- Tolerance
- ±0.5%
- Temperature Coefficient
- ±25ppm/℃
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 10,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.011 g
Overview
Key features
- High reliability: stable performance in high-temperature and high-humidity environments (85°C, 65% RH rated load, operating temperature range: -55°C ~ +155°C)
- High accuracy: low resistance tolerance and TCR
- High performance: low current noise, excellent linearity
- Reference standards: IEC 60115-8, JIS C 5201-8, JEITA RC-2133C
- AEC-Q200 compliant (except ERA1A)
- RoHS compliant
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | ARG02DTC1502#C2686469Viking · 0402 | Viking | 0402 | 4,500 | ₹1.08 · 4,500 in stock | View |
 | RN73H1ETTP1502B25#C2534575KOA · 0402 | KOA | 0402 | 9,350 | ₹18.42 · 9,350 in stock | View |
 | ERA2AEB153X#C490817PANASONIC · 0402 | PANASONIC | 0402 | 19,975 | ₹12.37 · 19,975 in stock | View |
 | RT0402BRD0715KL#C852545YAGEO · 0402 | YAGEO | 0402 | 83,040 | ₹3.92 · 83,040 in stock | View |
 | TC02H1502DT#C53159491FH · 0402 | FH | 0402 | 9,250 | ₹1.14 · 9,250 in stock | View |
