etasolutionDatasheet (PDF)
ETA9351Q4Y
0.45V~5.5V QFN-24L-EP(4x4) Power Management - Specialized RoHS
QFN-24L-EP(4x4)ROHS CompliantActive
Compact PMU with 3 Channels of 3.5A Fast Response, Adaptive COT Bucks
- Manufacturer
- etasolution
- Manufacturer part #
- ETA9351Q4Y
- Store part #
- C46682817
- Package / case
- QFN-24L-EP(4x4)
- Category
- Power Management - Specialized
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
5,346 in stock
#C46682817
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹75.19 | ₹75.19 |
| 10+ | ₹60.20 | ₹602.00 |
| 30+ | ₹52.59 | ₹1,577.70 |
| 100+ | ₹45.21 | ₹4,521.00 |
| 500+ | ₹40.85 | ₹20,425.00 |
| 1,000+ | ₹38.47 | ₹38,470.00 |
1 × ₹75.19
₹75.19
excl. GST
₹88.72 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 5,000 per reel
ETA9351Q4Y
₹75.19 for 1 + GST
Specifications
- Features
- Cycle-by-cycle current limiting;Hiccup current limiting;Light load efficient mode;Operating status indication
- Operating Temperature
- -40℃~+85℃
- Voltage - Supply
- 2.6V~5.5V
- Output Voltage
- 0.45V~5.5V
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 5,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.065 g
Overview
ETA9351 is a power management unit integrating three channels of high-frequency synchronous buck converters. Each channel delivers up to 3.5A output current with an input voltage range of 2.6V to 5.5V. Each channel employs an adaptive constant on-time control scheme, achieving fast transient response while maintaining a constant switching frequency. It eliminates the minimum on-time limitation typically required by fixed-frequency current-mode buck converters. Each channel can be independently enabled or disabled via a dedicated enable pin, providing flexibility for easy power-up sequencing. All three channels are integrated in a compact QFN4X4-24L package, significantly saving board space.
Applications
- Smart TV
- IP Camera
- Security Camera
- Dash Cam
- Set-Top Box
- Solid State Drive
- Tablet
- Other Battery-Powered Devices
Key features
- Adaptive constant on-time control
- Independent switch control
- Up to 95% efficiency
- Up to 91% efficiency at low output voltage
- Maximum output current up to 3.5A
- Feedback voltage 0.45V
- Excellent load transient response
- QFN4X4-24L package
