FOJANDatasheet (PDF)
FRL1206JR300TS
300mΩ ±5% 250mW 1206 Thick Film Resistor
1206RoHSActive
RES 300mΩ ±5% 250mW 1206
- Manufacturer
- FOJAN
- Manufacturer part #
- FRL1206JR300TS
- Store part #
- C2907398
- Package / case
- 1206
- Category
- Chip Resistor - Surface Mount
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,02,800 in stock
#C2907398
Stock & price checked 8 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 100+ | ₹0.8467 | ₹84.67 |
| 1,000+ | ₹0.7144 | ₹714.40 |
| 5,000+ | ₹0.5953 | ₹2,976.50 |
| 10,000+ | ₹0.5557 | ₹5,557.00 |
| 50,000+ | ₹0.516 | ₹25,800.00 |
| 1,00,000+ | ₹0.4895 | ₹48,950.00 |
100 × ₹0.8467
₹84.67
excl. GST
₹99.91 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 5,000 per reel
FRL1206JR300TS
₹84.67 for 100 + GST
Specifications
- Resistance
- 300mΩ
- Power(Watts)
- 250mW
- Voltage Rating
- 500V
- Operating Temperature
- -55℃~+155℃
- Type
- Thick Film Resistor
- Temperature Coefficient
- ±300ppm/℃
- Tolerance
- ±5%
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 5,000 / Reel
- Sold per
- Piece
- Minimum order
- 100 (multiples of 100)
- Unit weight
- 0.03 g
Overview
Applications
- Overcurrent protection for switching power supplies and audio equipment, voltage regulators, power converters, chargers, LED driver power supplies, portable devices, etc.
Key features
- Compact and lightweight
- Miniature and lightweight
- Stable electrical performance, high reliability
- RoHS compliant
- Halogen-free compliant
- Low resistance value
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | FRL1206FR300TS#C2907354FOJAN · 1206 | FOJAN | 1206 | 4,82,800 | ₹1.02 · 4,82,800 in stock | View |
 | FQL1206JR300TS#C55174692FOJAN · 1206 | FOJAN | 1206 | 11,460 | ₹7.67 · 11,460 in stock | View |
 | FQL1206FR300TS#C54830535FOJAN · 1206 | FOJAN | 1206 | 5,000 | ₹4.10 · 5,000 in stock | View |
