FS8205A
20V 9A 1.5W Surface Mount SOT-23-6
PopularSOT-23-6RoHSActive
MOSFET 20V 9A SOT-23-6
- Manufacturer
- TECH PUBLIC
- Manufacturer part #
- FS8205A
- Store part #
- C2830320
- Package / case
- SOT-23-6
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
50,980 in stock
#C2830320
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹6.63 | ₹66.30 |
| 100+ | ₹5.05 | ₹505.00 |
| 300+ | ₹4.26 | ₹1,278.00 |
| 3,000+ | ₹4.07 | ₹12,210.00 |
| 6,000+ | ₹3.60 | ₹21,600.00 |
| 9,000+ | ₹3.36 | ₹30,240.00 |
10 × ₹6.63
₹66.30
excl. GST
₹78.23 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
FS8205A
₹66.30 for 10 + GST
Specifications
- Output Capacitance(Coss)
- 65pF
- Ciss-Input Capacitance
- 466pF
- Pd - Power Dissipation
- 1.5W
- Configuration
- Common source
- Operating Temperature
- -55℃~+150℃
- Drain to Source Voltage
- 20V
- Current - Continuous Drain(Id)
- 6A
- Reverse Transfer Capacitance (Crss)
- 58pF
- RDS(on)
- 31.5mΩ@2.5V
- Number
- 2 N-Channel
- Gate Charge(Qg)
- 5.7nC@4.5V
- Vgs
- ±10V
- Gate Threshold Voltage (Vgs(th))
- 1.2V
- Type
- N-Channel
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.04 g
Overview
Applications
- Synchronous Rectification in DC/DC and AC/DC Converters
- Isolated Dc/DC Converters in Telecom and Industrial
Key features
- TrenchPower Technology
- Low RDS(ON)
- Low Gate Charge
- Optimized for Fast-switching Applications
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | UT8205AG-AG6#C2827644TECH PUBLIC · SOT-23-6 | TECH PUBLIC | SOT-23-6 | 2,830 | ₹7.22 · 2,830 in stock | View |
 | TPM8205ATS6#C2827645TECH PUBLIC · SOT-23-6 | TECH PUBLIC | SOT-23-6 | 1,070 | ₹8.56 · 1,070 in stock | View |
 | DMG6968UDM-TP#C48543185TECH PUBLIC · SOT-23-6 | TECH PUBLIC | SOT-23-6 | 2,150 | ₹6.05 · 2,150 in stock | View |
 | SSF2418E-TP#C48543214TECH PUBLIC · SOT-23-6 | TECH PUBLIC | SOT-23-6 | 2,790 | ₹7.18 · 2,790 in stock | View |
 | 8205S#C48886779TECH PUBLIC · SOT-23-6 | TECH PUBLIC | SOT-23-6 | 2,610 | ₹5.94 · 2,610 in stock | View |
Questions about FS8205A
Is the TECH PUBLIC FS8205A Compatible With Dual N-Channel Systems Requiring Low On-Resistance?
Yes, it is highly compatible. The FS8205A is a dual N-channel MOSFET designed to fit seamlessly into systems configured for common-drain or dual-switch setups, offering a low RDS(on) of 31.5mΩ at a 2.5V gate drive to optimize efficiency.
What Are the Recommended Replacements or Alternatives for This Component?
While the FS8205A is an industry-standard dual N-channel MOSFET in a SOT-23-6 package, you can explore over 64,000 similar products in the Single FETs, MOSFETs category on LCSC Electronics. Be sure to verify the pinout configuration, RDS(on), and voltage ratings when selecting an alternative.
In What Application Scenarios Is This MOSFET Best Utilized?
This device features TrenchPower technology and is optimized for fast-switching applications. It is ideally used for synchronous rectification in DC/DC and AC/DC converters, as well as isolated DC/DC converters within telecommunications and industrial equipment.
What Are the Core Technical Specifications of the FS8205A?
The FS8205A features a Drain to Source Voltage (Vds) of 20V, a Continuous Drain Current (Id) of 6A, and a power dissipation (Pd) of 1.5W. It operates reliably across a wide operating temperature range from -55°C to +150°C.
What Should Be Considered During the Board Layout and Implementation of This SOT-23-6 Package?
When implementing the FS8205A, ensure that thermal dissipation is managed correctly since the compact SOT-23-6 package handles up to 1.5W of power. Proper PCB trace width should be allocated for the 6A continuous current, and gate drive voltages should respect the 1.2V gate threshold voltage (Vgs(th)) for clean switching.
