FT24C32A-ELR-T
32Kbit 1MHz I2C SOT-23-5 Memory
32K Bit Serial EEPROM
- Manufacturer
- FMD(Fremont Micro Devices)
- Manufacturer part #
- FT24C32A-ELR-T
- Store part #
- C5263776
- Package / case
- SOT-23-5
- Category
- Memory
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
3,380 in stock
#C5263776
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹12.91 | ₹64.55 |
| 50+ | ₹10.23 | ₹511.50 |
| 150+ | ₹8.88 | ₹1,332.00 |
| 500+ | ₹7.87 | ₹3,935.00 |
| 3,000+ | ₹6.73 | ₹20,190.00 |
| 6,000+ | ₹6.32 | ₹37,920.00 |
5 × ₹12.91
₹64.55
excl. GST
₹76.17 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
FT24C32A-ELR-T
₹64.55 for 5 + GST
Specifications
- Operating Temperature
- -40℃~+85℃
- Features
- Hardware write protection function;Built-in power-on reset (POR);Noise suppression function
- Memory Size
- 32Kbit
- Voltage - Supply
- 1.7V~5.5V;3mA
- Clock Frequency
- 1MHz
- Access Time
- 900ns
- Data Retention - TDR (Year)
- 100 Years
- Write Cycle Time(tWC)
- 5ms
- Standby Supply Current
- 1uA
- Write Cycle Endurance
- 1,000,000 cycles
- Interface
- I2C
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.03 g
Overview
The FT24C32A series are 32,768 bits of serial Electrical Erasable and Programmable Read Only Memory, commonly known as EEPROM. They are organized as 4096 words of 8 bits (one byte) each. The devices are fabricated with proprietary advanced CMOS process for low power and low voltage applications. These devices are available in standard 8-lead DIP, 8-lead SOP, 8-lead MSOP, 8-lead TSSOP, 8-lead DFN, 8-lead UDFN, 5-lead SOT23, and 5-lead TSOT23 packages. A standard 2-wire serial interface is used to address all read and write functions. Our extended VCC range (1.7V to 5.5V) devices enables wide spectrum of applications.
Key features
- Low voltage and low power operations: FT24C32A: VCC = 1.7V to 5.5V
- 32 bytes page write mode
- Partial page write operation allowed
- Internally organized: 4,096x8 (32K)
- Standard 2-wire bi-directional serial interface
- Schmitt trigger, filtered inputs for noise protection
- Self-timed Write Cycle (5ms maximum)
- 1000 kHz (2.5V - 5V), 400 kHz (1.7V) Compatibility
- Automatic erase before write operation
- Write protect pin for hardware data protection
- High reliability: typically 1,000,000 cycles endurance
- 100 years data retention
- Industrial temperature range (-40℃ to 85℃)
- Standard 8-lead DIP/SOP/MSOP/TSSOP/DFN/UDFN and 5-lead SOT23/TSOT23 Pb-free packages
