GRDatasheet (PDF)
GR5800A30PR
Linear Voltage Regulator IC Positive Fixed 1 Output 100mA SOT-89
SOT-89RoHSActive
Ultra-low power linear voltage regulator
- Manufacturer
- GR
- Manufacturer part #
- GR5800A30PR
- Store part #
- C19631804
- Package / case
- SOT-89
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,530 in stock
#C19631804
Stock & price checked 3 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹8.07 | ₹80.70 |
| 100+ | ₹6.50 | ₹650.00 |
| 300+ | ₹5.70 | ₹1,710.00 |
| 1,000+ | ₹5.11 | ₹5,110.00 |
| 5,000+ | ₹4.63 | ₹23,150.00 |
| 10,000+ | ₹4.39 | ₹43,900.00 |
10 × ₹8.07
₹80.70
excl. GST
₹95.23 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 1,000 per reel
GR5800A30PR
₹80.70 for 10 + GST
Specifications
- Output Voltage
- 3V
- Number of Outputs
- 1
- Operating Temperature
- -25℃~+70℃
- Supply Current (Iq)
- 1uA
- Output Configuration
- Positive
- Output Current
- 100mA
- Operating Voltage
- 15V
- Output Type
- Fixed
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- Packaging
- Tape & Reel (TR)
- Standard pack
- 1,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.17 g
Overview
GR5800xx series are ultra-low power high-voltage regulators fabricated using CMOS process, supporting a maximum input voltage of 15V and an output voltage range of 3V - 5V. They feature high-accuracy output voltage, ultra-low quiescent current, and ultra-low dropout voltage.
Applications
- Portable handheld devices, various communication equipment
- Audio/video devices
- Security surveillance equipment
Key features
- Low power consumption: typical 1μA
- Low dropout voltage: typical 0.1V
- Low temperature drift: typical 50 ppm/℃
- High input voltage: up to 15V
- High-accuracy output voltage: ±3% tolerance
- Package: TO-92, SOT89-3, SOT23-3
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | GR7130#C19631762GR · SOT-89-3 | GR | SOT-89-3 | 1,000 | ₹3.73 · 1,000 in stock | View |
 | GR7530#C19631768GR · SOT-89-3 | GR | SOT-89-3 | 2,700 | ₹3.68 · 2,700 in stock | View |
 | GR7330-A#C19631793GR · SOT-89-3 | GR | SOT-89-3 | 430 | ₹6.35 · 430 in stock | View |
 | HT7530#C49191522GR · SOT-89-3 | GR | SOT-89-3 | 340 | ₹5.11 · 340 in stock | View |
