Gainsil

GS1G157-CR

1.65V~5.5V 0.1uA 3.8ns@3.3V,50pF Power-off protection SC-70-6 Signal Switches, Multiplexers, Decoders

SC-70-6RoHSActive

Manufacturer: Gainsil
Manufacturer part #: GS1G157-CR
Store part #: C49326084
Package / case: SC-70-6
Category: Signal Switches, Multiplexers, Decoders
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

3,000 in stock

#C49326084

Stock & price checked 5 days ago

Quantity	Unit price	Pack price
5+	₹43.28	₹216.40
50+	₹34.23	₹1,711.50
150+	₹30.35	₹4,552.50
500+	₹25.52	₹12,760.00
3,000+	₹23.36	₹70,080.00
6,000+	₹22.08	₹1,32,480.00

Quantity (min 5, multiples of 5)

5 × ₹43.28

₹216.40

excl. GST

₹255.35 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 3,000 per reel

GS1G157-CR

₹216.40 for 5 + GST

Specifications

Voltage - Supply: 1.65V~5.5V
Operating Temperature: -40℃~+125℃
Quiescent Current: 0.1uA
Current - Output High(IOH): 24mA
Propagation Delay: 3.8ns@3.3V,50pF
Function: Power-off protection
Current - Output Low(IOL): 24mA

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.046 g

Overview

GS1G157 is a single 2-input multiplexer designed for VCC operating voltages from 1.65V to 5.5V. The device selects data from two data inputs (I0 and I1) under the control of a common data select input (S). The state of the common data select input determines which specific register the data comes from. The output (Y) presents the selected data in non-inverting form. The GS1G157 fully supports partial power-down applications using IOFF. The IOFF circuit disables the output to prevent destructive current backflow when the device is powered down. The device is available in a green SC70-6 package and operates over an ambient temperature range of -40°C to +125°C.
