HOLTEKDatasheet (PDF)
HT7544-7
Linear Voltage Regulator IC Positive Fixed 1 Output 100mA SOT-23-5
SOT-23-5RoHSActive
30V, 100mA TinyPower LDO with protection function
- Manufacturer
- HOLTEK
- Manufacturer part #
- HT7544-7
- Store part #
- C259869
- Package / case
- SOT-23-5
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,225 in stock
#C259869
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹22.80 | ₹114.00 |
| 50+ | ₹18.05 | ₹902.50 |
| 150+ | ₹16.01 | ₹2,401.50 |
| 500+ | ₹13.47 | ₹6,735.00 |
| 3,000+ | ₹12.34 | ₹37,020.00 |
| 6,000+ | ₹11.67 | ₹70,020.00 |
5 × ₹22.80
₹114.00
excl. GST
₹134.52 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
HT7544-7
₹114.00 for 5 + GST
Specifications
- Output Voltage
- 4.4V
- Number of Outputs
- 1
- Operating Temperature
- -40℃~+85℃@(Ta)
- Supply Current (Iq)
- 2.5uA
- Output Configuration
- Positive
- Operating Voltage
- 30V
- Output Current
- 100mA
- Features
- Enable control;Over Current Protection;Thermal shutdown;Output discharge
- Output Type
- Fixed
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.041 g
Overview
The HT75xx-7 series is a group of low-power, high-voltage regulators implemented in CMOS technology. CMOS technology ensures low dropout voltage and low quiescent current characteristics. The input voltage can be as high as 30V, with several fixed output voltage options ranging from 2.1V to 12.0V. When the CE input pin is low, a fast discharge path pulls down the output voltage through a built-in pull-down resistor. Even if the output pin is shorted to ground, the built-in overcurrent protection circuit prevents damage to the device. The overtemperature protection circuit ensures that the junction temperature will not exceed 160°C.
Applications
- Battery-powered devices
- Communication equipment
- Audio/video devices
Key features
- Low power consumption
- Low dropout voltage
- Low temperature coefficient
- High input voltage (up to 30V)
- Output voltage accuracy: ±2%
- Overcurrent protection
- Over-temperature protection
- Chip enable/disable function
- Package types: 3-pin SOT89, 5-pin SOT23
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | HT7544-2#C259650HOLTEK · SOT-23-5 | HOLTEK | SOT-23-5 | 10 | ₹11.09 · 10 in stock | View |
| GP2001-44HT5R#C48997240GUQIAO Microelectronics · SOT-23-5 | GUQIAO Microelectronics | SOT-23-5 | On request | Price on request | Quote | |
 | AP7383-44WW-7#C5564327DIODES · SOT-25 | DIODES | SOT-25 | On request | Price on request | Quote |
