HOLTEKDatasheet (PDF)
HT78R33B
3.3V Positive Fixed SOT89 Voltage Regulators - Linear, Low Drop Out (LDO) Regulators
SOT89RoHSActive
- Manufacturer
- HOLTEK
- Manufacturer part #
- HT78R33B
- Store part #
- C53223864
- Package / case
- SOT89
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,695 in stock
#C53223864
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹13.26 | ₹66.30 |
| 50+ | ₹11.56 | ₹578.00 |
| 150+ | ₹10.72 | ₹1,608.00 |
| 1,000+ | ₹10.08 | ₹10,080.00 |
| 2,000+ | ₹9.58 | ₹19,160.00 |
| 5,000+ | ₹9.33 | ₹46,650.00 |
5 × ₹13.26
₹66.30
excl. GST
₹78.23 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 1,000 per reel
HT78R33B
₹66.30 for 5 + GST
Specifications
- Output Voltage
- 3.3V
- Number of Outputs
- 1
- Operating Temperature
- -40℃~+105℃
- Supply Current (Iq)
- 3uA
- Output Configuration
- Positive
- Output Current
- 500mA
- Operating Voltage
- 20V
- Output Type
- Fixed
- Features
- Enable control;Over Current Protection;Thermal shutdown
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 1,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.115 g
Overview
The HT78Rxx series positive linear regulators feature low quiescent current and low dropout characteristics, making them suitable for battery-powered applications. Available in space-saving packages, the series delivers a continuous output current of 500mA. Multiple fixed output voltage options are provided, with voltage and current adjustment achievable via external components. The series integrates thermal shutdown and current limiting protection to handle demanding operating conditions.
Applications
- Portable electronics
- Wireless devices
- Cordless phones
- PC peripherals
- Battery-powered devices
- Electronic scales
Key features
- Fixed output voltages: 1.5V, 3.0V, 3.3V, 3.5V, 5.0V
- High accuracy: ±2%
- Low dropout: 60mV (typical), VOUT = 5.0V @ 500mA
- Maximum input voltage: 20V
- Guaranteed output current: 500mA
- Low quiescent current: 3μA (typical)
- Current limiting
- Thermal shutdown
- Package types: 3-pin SOT89 and 5-pin SOT23
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | PJ73HM33SQ#C42436934PJSEMI · SOT-89 | PJSEMI | SOT-89 | 185 | ₹18.06 · 185 in stock | View |
 | DS8404-33A3#C48533060DSTECH · SOT-89-3 | DSTECH | SOT-89-3 | 280 | ₹10.66 · 280 in stock | View |
 | DS8242-33A3#C5884129DSTECH · SOT-89-3 | DSTECH | SOT-89-3 | 1,590 | ₹5.98 · 1,590 in stock | View |
 | DS8242-33A3R#C5884131DSTECH · SOT-89-3R | DSTECH | SOT-89-3R | 235 | ₹13.51 · 235 in stock | View |
 | MD7612A33PA1#C2978350Mingda Microelectronics · SOT-89-3 | Mingda Microelectronics | SOT-89-3 | 190 | ₹23.42 · 190 in stock | View |
