HANSCHIP semiconductorDatasheet (PDF)
HX24LC256BDRG
256Kbit 1MHz I2C SOIC-8 Memory RoHS
SOIC-8ROHS CompliantActive
EEPROM two-wire serial interface
- Manufacturer
- HANSCHIP semiconductor
- Manufacturer part #
- HX24LC256BDRG
- Store part #
- C2987263
- Package / case
- SOIC-8
- Category
- Memory
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
4,170 in stock
#C2987263
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹36.84 | ₹184.20 |
| 50+ | ₹29.55 | ₹1,477.50 |
| 150+ | ₹26.42 | ₹3,963.00 |
| 500+ | ₹22.53 | ₹11,265.00 |
| 2,500+ | ₹19.63 | ₹49,075.00 |
| 5,000+ | ₹18.59 | ₹92,950.00 |
5 × ₹36.84
₹184.20
excl. GST
₹217.36 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
HX24LC256BDRG
₹184.20 for 5 + GST
Specifications
- Operating Temperature
- -40℃~+85℃
- Features
- Hardware write protection function;Noise suppression function;Software write protection function
- Memory Size
- 256Kbit
- Voltage - Supply
- 1.8V~5.5V;2mA
- Clock Frequency
- 1MHz
- Access Time
- 0.9us
- Data Retention - TDR (Year)
- 100 Years
- Write Cycle Time(tWC)
- 5ms
- Standby Supply Current
- 3uA
- Write Cycle Endurance
- 1,000,000 cycles
- Interface
- I2C
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.15 g
Overview
The HX24LC128/256 provides 131,072/262,144 bits of serial EEPROM, organized as 4,096 words of 8 bits each. The device is optimized for a wide range of industrial and commercial applications where low power consumption and low voltage operation are essential. The HX24LC128/256 is available in space-saving 8-pin DIP, 8-pin SOP8, and 8-pin MSOP packages, and is accessible via a two-wire serial interface.
Key features
- Wide voltage operation, VCC = 1.8V ~ 5.5V
- Low-power device (ISB = 3 μA @ 5.5V), operating temperature range: -40°C ~ +85°C, internal organization: 16,384 X 8 (128K) / 32,768 X 8 (256K), two-wire serial interface
- Schmitt trigger inputs with noise suppression filtering, bidirectional data transfer protocol
- 1MHz (5V) / 400kHz (1.8V, 2.7V, 3.3V) compatible
- Write protect pin for hardware data protection, 64-byte page (128K/256K) write mode with partial page write support
- Self-timed write cycle (5ms max), high reliability; endurance: 1,000,000 write cycles, data retention: 100 years
- 8-pin DIP, 8-pin JEDEC SOP, and 8-pin MSOP packages
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | HX24C256DRG#C5145458HANSCHIP semiconductor · SOP-8 | HANSCHIP semiconductor | SOP-8 | 2,415 | ₹23.09 · 2,415 in stock | View |
 | AT24C256CDRG#C19723712HANSCHIP semiconductor · SOP-8 | HANSCHIP semiconductor | SOP-8 | 3,040 | ₹30.20 · 3,040 in stock | View |
