IMP811T-TD
Supervisor 1 Channel SOT-143
Low-Voltage Reset Detector
- Manufacturer
- TDSEMIC
- Manufacturer part #
- IMP811T-TD
- Store part #
- C42421912
- Package / case
- SOT-143
- Category
- Supervisors
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
3,225 in stock
#C42421912
Stock & price checked 2 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹15.14 | ₹75.70 |
| 50+ | ₹11.92 | ₹596.00 |
| 150+ | ₹10.31 | ₹1,546.50 |
| 500+ | ₹9.10 | ₹4,550.00 |
| 2,500+ | ₹8.14 | ₹20,350.00 |
| 5,000+ | ₹7.65 | ₹38,250.00 |
5 × ₹15.14
₹75.70
excl. GST
₹89.33 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
IMP811T-TD
₹75.70 for 5 + GST
Specifications
- Reset Timeout
- 900ms
- Operating Temperature
- -20℃~+70℃
- Function
- Manual reset input
- Reset Active Level
- Active Low
- standby current
- 1uA
- Voltage - Supply
- 1V~6V
- ChipType
- Voltage Detector
- Threshold Voltage
- 3.08V
- Number of Voltages Monitored
- 1
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 2 (1 year)
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.037 g
Overview
The IMP811T-TD series is a microprocessor reset IC with an enable control pin, featuring voltage monitoring capability for supervising the supply voltage of microcontrollers or other logic systems. The IC generates a reset signal to the system during power-up, power-down, power-saving mode, or when the supply voltage falls below the preset threshold voltage Vth. When the supply voltage rises above Vth during power-up or recovery, or when the enable control pin transitions from low to high, the VOUT output will go high after a delay of Trp. If the input voltage falls below Vth or the enable control pin is held low, VOUT will be driven low. This product requires no external components for a simple implementation.
Applications
- Battery-powered equipment
- Power failure detectors
- Computers
- Microprocessors
- Nonvolatile RAM signal memory protectors
Key features
- Low power consumption: 2μA (typical) @ VMR = VCC
- Wide operating voltage range: 1V ~ 6.0V
- VCC transient noise immunity
- Simple application, no external components required
- Built-in reset delay time: 500ms (typical)
- High-accuracy reset voltage: ±2.5%
- Enable control pin, active low
- Compact package: SOT143
