IMT40R045M2HXTMA1
400V 43A 150W 56.2mΩ 1 N-channel N-Channel HSOF-8 Single FETs, MOSFETs RoHS
HSOF-8ROHS CompliantActive
- Manufacturer
- Infineon
- Manufacturer part #
- IMT40R045M2HXTMA1
- Store part #
- C31024629
- Package / case
- HSOF-8
- Category
- Single FETs, MOSFETs
- Packaging
- Tube-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
12 in stock
#C31024629
Stock & price checked 43 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹961.07 | ₹961.07 |
| 10+ | ₹832.54 | ₹8,325.40 |
| 30+ | ₹754.12 | ₹22,623.60 |
| 100+ | ₹688.30 | ₹68,830.00 |
1 × ₹961.07
₹961.07
excl. GST
₹1,134.06 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,000 per tube
IMT40R045M2HXTMA1
₹961.07 for 1 + GST
Specifications
- Operating Temperature
- -55℃~+175℃
- Drain to Source Voltage
- 400V
- Current - Continuous Drain(Id)
- 43A
- Output Capacitance(Coss)
- 100pF
- Ciss-Input Capacitance
- 910pF
- Pd - Power Dissipation
- 150W
- Reverse Transfer Capacitance (Crss)
- 9pF
- RDS(on)
- 56.2mΩ
- Number
- 1 N-channel
- Gate Charge(Qg)
- 21nC
- Gate Threshold Voltage (Vgs(th))
- 5.6V
- Type
- N-Channel
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tube-packed
- Standard pack
- 2,000 / Tube
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 1.023 g
Overview
Applications
- Switching power supplies
- Solar PV inverters
- Energy storage, UPS, and battery formation
- Class-D audio
- Motor drives
Key features
- High-frequency switching and synchronous rectification
- Commutation-robust fast body diode with low Qfr
- Low temperature dependence of RDS(on)
- Nominal gate threshold voltage, VGS(th) = 4.5 V
- Recommended gate drive voltage 0 V to 18 V
- .XT interconnect technology for best-in-class thermal performance
- 100% avalanche tested
