ITS4141N
1 Active High High Side Switch SOT-223-4 Power Distribution Switches, Load Drivers RoHS
SOT-223-4ROHS3 CompliantActive
Smart High-Side Power Switch for Industrial Applications
- Manufacturer
- Infineon
- Manufacturer part #
- ITS4141N
- Store part #
- C538473
- Package / case
- SOT-223-4
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
3,985 in stock
#C538473
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹227.58 | ₹227.58 |
| 10+ | ₹188.92 | ₹1,889.20 |
| 30+ | ₹167.65 | ₹5,029.50 |
| 100+ | ₹140.50 | ₹14,050.00 |
| 500+ | ₹129.87 | ₹64,935.00 |
| 1,000+ | ₹125.09 | ₹1,25,090.00 |
1 × ₹227.58
₹227.58
excl. GST
₹268.54 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 4,000 per reel
ITS4141N
₹227.58 for 1 + GST
Specifications
- Operating Temperature
- -30℃~+85℃
- Features
- Overcurrent Protection;Short-Circuit Protection;Over temperature protection;Overvoltage protection;Under-voltage lockout;Reverse voltage protection
- number of channels
- 1
- Control Input Logic
- Active High
- Operating Voltage
- 12V~45V
- RDS(on)
- 200mΩ
- Type
- High Side Switch
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 4,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.149 g
Overview
N channel vertical power FET with charge pump, ground referenced CMOS compatible input, monolithically integrated in Smart SIPMOS technology. Providing embedded protective functions.
Applications
- All types of resistive, inductive and capacitive loads
- μC compatible power switch for 12V and 24V DC industrial applications
- Replaces electromechanical relays and discrete circuits
Key features
- Short circuit protection
- Current limitation
- Overload protection
- Overvoltage protection (including load dump)
- Undervoltage shutdown with autorestart and hysteresis
- Switching inductive loads
- Clamp of negative voltage at output with inductive loads
- CMOS compatible input
- Thermal shutdown with restart
- ESD - Protection
- Loss of GND and loss of Vbb protection
- Very low standby current
- Reverse battery protection with external resistor
- Improved electromagnetic compatibility (EMC)
