JoulWatt Tech

JW5033STSOTB#TRPB

Step-down type 800kHz Adjustable 800mV~15V 2A TSOT-23-6 Voltage Regulators - DC DC Switching Regulators

TSOT-23-6RoHSActive

Synchronous Step-Down Converter JW5033S

Manufacturer: JoulWatt Tech
Manufacturer part #: JW5033STSOTB#TRPB
Store part #: C324577
Package / case: TSOT-23-6
Category: Voltage Regulators - DC DC Switching Regulators
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

16,525 in stock

#C324577

Stock & price checked 6 days ago

Quantity	Unit price	Pack price
5+	₹17.28	₹86.40
50+	₹13.61	₹680.50
150+	₹11.79	₹1,768.50
500+	₹10.41	₹5,205.00
3,000+	₹9.70	₹29,100.00
6,000+	₹9.16	₹54,960.00

Quantity (min 5, multiples of 5)

5 × ₹17.28

₹86.40

excl. GST

₹101.95 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 3,000 per reel

JW5033STSOTB#TRPB

₹86.40 for 5 + GST

Specifications

Operating Temperature: -40℃~+125℃
Function: Step-down type
Frequency - Switching: 800kHz
Number of Outputs: 1
Features: Cycle-by-cycle current limiting;Hiccup current limiting;Light load efficient mode;Overcurrent Protection
Output Type: Adjustable
Topology: Buck
Operating Voltage: 3.7V~18V
Switch tube (built-in/external): Built-in
Output Voltage: 800mV~15V
Output Current: 2A
Quiescent Current: 150uA

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.05 g

Overview

The JW5033S is a current mode monolithic buck regulator. With an input voltage range of 3.7V - 18V, the JW5033S delivers 2A of continuous output current with two integrated N-Channel MOSFETs. At light loads, regulators operate in low frequency to maintain high efficiency and low output ripple. The JW5033S guarantees robustness with short circuit protection, thermal protection, current run-away protection, and input under voltage lockout. The JW5033S is available in a 6-pin TSOT23-6 and SOT563 package, which provides a compact solution with minimal external components. The JW5033S is a synchronous, current-mode, step-down regulator. It regulates input voltages from 3.7V to 18V down to an output voltage as low as 0.8V, and is capable of supplying up to 2A of load current.

Applications

Distributed Power Systems
Networking Systems
FPGA, DSP, ASIC Power Supplies
Green Electronics/ Appliances
Notebook Computers

Key features

3.7V to 18V operating input range 2A output current
Up to 95% efficiency
High efficiency at light load
800kHz Switching frequency
Input under voltage lockout
Start-up current run-away protection
Over current protection and Hiccup
Thermal protection
Available in TSOT23-6 and SOT563 package
