STDatasheet (PDF)
L78L09ACZ-TR
9V Positive Fixed TO-92-3 Voltage Regulators - Linear, Low Drop Out (LDO) Regulators RoHS
TO-92-3ROHS3 CompliantActive
0.1A Positive Voltage Regulator
- Manufacturer
- ST
- Manufacturer part #
- L78L09ACZ-TR
- Store part #
- C2970225
- Package / case
- TO-92-3
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
9,630 in stock
#C2970225
Stock & price checked 3 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹12.83 | ₹64.15 |
| 50+ | ₹12.52 | ₹626.00 |
| 150+ | ₹12.30 | ₹1,845.00 |
| 500+ | ₹12.09 | ₹6,045.00 |
5 × ₹12.83
₹64.15
excl. GST
₹75.70 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,000 per reel
L78L09ACZ-TR
₹64.15 for 5 + GST
Specifications
- Output Voltage
- 9V
- Number of Outputs
- 1
- Operating Temperature
- 0℃~+125℃@(Tj)
- Supply Current (Iq)
- 6mA
- Output Configuration
- Positive
- Output Current
- 100mA
- Operating Voltage
- 30V
- Features
- Thermal shutdown;Short Circuit Protection
- Output Type
- Fixed
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.42 g
Overview
The L78L series of three-terminal positive regulators employ internal current limiting and thermal shutdown, making them essentially indestructible. If adequate heat-sink is provided, they can deliver up to 100 mA output current. They are intended as fixed voltage regulators in a wide range of applications including local or oncard regulation for elimination of noise and distribution problems associated with single-point regulation. In addition, they can be used with power pass elements to make high-current voltage regulators. The L78L series used as Zener diode/resistor combination replacement, offers e improvement along with lower quiescent current and lower noise.
Key features
- Output current up to 100 mA
- Output voltages of 3.3; 5; 6; 8; 9; 10; 12; 15; 18; 24 V
- Thermal overload protection
- Short-circuit protection
- No external components are required
- Available in either ± 4% (A) or ± 8% (C) selection
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | L78L09ACZ-AP#C262912ST · TO-92-3 | ST | TO-92-3 | 385 | ₹21.51 · 385 in stock | View |
 | L78L09ABZ#C2970629ST · TO-92 | ST | TO-92 | 50 | ₹26.00 · 50 in stock | View |
 | CJ78L09#C8613JSCJ · TO-92 | JSCJ | TO-92 | 70 | ₹10.21 · 70 in stock | View |
 | CJ78L09C-TAB-ABG#C20622071JSCJ · TO-92 | JSCJ | TO-92 | 100 | ₹9.87 · 100 in stock | View |
 | UA78L09ACLPR#C2877253TI · TO-92-3 | TI | TO-92-3 | 995 | ₹43.63 · 995 in stock | View |
