LM1117IMPX-5.0/NOPB
5V Positive Fixed SOT-223-3 Voltage Regulators - Linear, Low Drop Out (LDO) Regulators RoHS
SOT-223-3ROHS3 CompliantActive
800mA 15V linear regulator
- Manufacturer
- TI
- Manufacturer part #
- LM1117IMPX-5.0/NOPB
- Store part #
- C41202
- Package / case
- SOT-223-3
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
27,020 in stock
#C41202
Stock & price checked 3 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹47.80 | ₹239.00 |
| 50+ | ₹39.02 | ₹1,951.00 |
| 150+ | ₹35.26 | ₹5,289.00 |
| 500+ | ₹29.26 | ₹14,630.00 |
| 2,000+ | ₹27.17 | ₹54,340.00 |
| 4,000+ | ₹25.92 | ₹1,03,680.00 |
5 × ₹47.80
₹239.00
excl. GST
₹282.02 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,000 per reel
LM1117IMPX-5.0/NOPB
₹239.00 for 5 + GST
Specifications
- Output Voltage
- 5V
- Number of Outputs
- 1
- Operating Temperature
- 0℃~+125℃@(Tj)
- Supply Current (Iq)
- 5mA
- Output Configuration
- Positive
- Operating Voltage
- 15V
- Output Current
- 800mA
- Features
- Over Current Protection;Thermal shutdown
- Output Type
- Fixed
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.288 g
Overview
The LM1117 is a low dropout voltage regulator with a dropout of 1.2 V at 800 mA of load current. The LM1117 is available in an adjustable version, which can set the output voltage from 1.25 to 13.8 V with only two external resistors. In addition, it is available in five fixed voltages, 1.8 V, 2.5 V, 3.3 V, and 5 V. The LM1117 offers current limiting and thermal shutdown. Its circuit includes a Zener trimmed bandgap reference to assure output voltage accuracy to within ±1%. A minimum of 10 μF tantalum capacitor is required at the output to improve the transient response and stability.
Applications
- Post Regulator for Switching DC–DC Converter
- High Efficiency Linear Regulators
- Battery Chargers
- Portable Instrumentation
- Active SCSI Termination Regulator
Key features
- Available in 1.8 V, 2.5 V, 3.3 V, 5 V, and Adjustable Versions
- Space-Saving SOT-223 and WSON Packages
- Current Limiting and Thermal Protection
- Output Current 800 mA
- Line Regulation 0.2% (Maximum)
- Load Regulation 0.4% (Maximum)
- Temperature Range: LM1117: 0°C to 125°C; LM1117I: -40°C to 125°C
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | LM1117IMP-5.0/NOPB#C2862483TI · SOT-223-4 | TI | SOT-223-4 | 1,175 | ₹54.75 · 1,175 in stock | View |
 | LM1117MP-5.0/NOPB#C131933TI · SOT-223-3 | TI | SOT-223-3 | 105 | ₹49.55 · 105 in stock | View |
 | LM1117MPX-5.0/NOPB#C730069TI · SOT-223-4 | TI | SOT-223-4 | 6,187 | ₹60.83 · 6,187 in stock | View |
 | AMS1117-5.0#C18164486GR · SOT-223 | GR | SOT-223 | 1,460 | ₹5.08 · 1,460 in stock | View |
 | LD1117S50TR#C134077ST · SOT-223-3 | ST | SOT-223-3 | 24,205 | ₹25.90 · 24,205 in stock | View |
