LM2950GTA-3.3
3.3V Positive Fixed TO-92-3 Voltage Regulators - Linear, Low Drop Out (LDO) Regulators RoHS
TO-92-3ROHS CompliantActive
100mA Low Dropout Voltage Regulator
- Manufacturer
- HTC
- Manufacturer part #
- LM2950GTA-3.3
- Store part #
- C596331
- Package / case
- TO-92-3
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,330 in stock
#C596331
Stock & price checked 29 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹22.40 | ₹112.00 |
| 50+ | ₹17.78 | ₹889.00 |
| 150+ | ₹15.80 | ₹2,370.00 |
| 500+ | ₹13.34 | ₹6,670.00 |
| 2,000+ | ₹12.24 | ₹24,480.00 |
| 4,000+ | ₹11.58 | ₹46,320.00 |
5 × ₹22.40
₹112.00
excl. GST
₹132.16 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 2,000 per reel
LM2950GTA-3.3
₹112.00 for 5 + GST
Specifications
- Output Voltage
- 3.3V
- Number of Outputs
- 1
- Operating Temperature
- -25℃~+85℃@(Tj)
- Supply Current (Iq)
- 75uA
- Output Configuration
- Positive
- Output Current
- 100mA
- Operating Voltage
- 30V
- Features
- Thermal shutdown;Enable control
- Output Type
- Fixed
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.326 g
Overview
The LM2950G is a low power voltage regulator. This device is an excellent choice for use in battery-powered application such as cordless telephones, radio-control systems, and portable computers. The LM2950G features a very low quiescent current (75uA typ.) and a very low drop output voltage (typ. 40mV at a light load and 380mV at 100mA). Furthermore, a tight initial Output voltage tolerance of 0.5% Typ., an extremely good load and line regulation of 0.05% Typical, and a very low output temperature coefficient - all that makes the LM2950G very useful as a lowpower voltage reference.
Applications
- Battery-powered systems
- Cordless telephones
- Radio-control systems
- Portable / Palm-top / Notebook computers
- Portable consumer equipment
- Portable instrumentation
- Automotive electronics
- SMPS post-regulator
- Voltage reference
Key features
- High accuracy output voltage
- Guaranteed 100 mA output
- Very low quiescent current
- Low dropout voltage
- Extremely tight load and line regulation
- Very low temperature coefficient
- Needs Output low-ESR ceramic capacitor for stability
- Logic-controlled electronic shutdown
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | LP2950CZ-3.3/NOPB#C2873321TI · TO-92-3 | TI | TO-92-3 | 10 | ₹209.23 · 10 in stock | View |
 | LP2950-33LPE3#C352869TI · TO-92-3 | TI | TO-92-3 | 310 | ₹202.59 · 310 in stock | View |
 | LP2950CZ-3.3RAG#C903065onsemi · TO-92 | onsemi | TO-92 | 54 | ₹109.07 · 54 in stock | View |
 | LP2950ACZ-3.3G#C233209onsemi · TO-92 | onsemi | TO-92 | 491 | ₹103.45 · 491 in stock | View |
 | LP2950CZ-3.3/LFT3#C2864799TI · TO-92-3 | TI | TO-92-3 | 60 | ₹109.85 · 60 in stock | View |
