ADIDatasheet (PDF)
LT3045EDD-1#TRPBF
0V~15V Positive Adjustable DFN-12(3x3) Voltage Regulators - Linear, Low Drop Out (LDO) Regulators RoHS
DFN-12(3x3)ROHS3 CompliantActive
20V, 500mA, Ultralow Noise, Ultrahigh PSRR Linear Regulator with VIOC Control
- Manufacturer
- ADI
- Manufacturer part #
- LT3045EDD-1#TRPBF
- Store part #
- C666576
- Package / case
- DFN-12(3x3)
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,232 in stock
#C666576
Stock & price checked 2 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹1,274.90 | ₹1,274.90 |
| 10+ | ₹1,127.16 | ₹11,271.60 |
| 30+ | ₹972.89 | ₹29,186.70 |
| 100+ | ₹897.30 | ₹89,730.00 |
1 × ₹1,274.90
₹1,274.90
excl. GST
₹1,504.38 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
LT3045EDD-1#TRPBF
₹1,274.90 for 1 + GST
Specifications
- Output Voltage
- 0V~15V
- Number of Outputs
- 1
- Operating Temperature
- -40℃~+125℃@(Tj)
- Supply Current (Iq)
- 2.3mA
- Output Configuration
- Positive
- Output Current
- 500mA
- Operating Voltage
- 20V
- Features
- Adjustable current limiting;Operating status indication;Enable control;Input under-voltage protection;Reverse polarity voltage protection;Reverse-polarity current protection;Thermal shutdown;Short Circuit Protection;Over Current Protection
- Output Type
- Adjustable
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.2 g
Overview
The LT3045-1 is a high performance low dropout linear regulator featuring ultralow noise and ultrahigh PSRR architecture for powering noise sensitive applications. Designed as a precision current reference followed by a high performance voltage buffer, the LT3045-1 can be easily paralleled to further reduce noise, increase output current and spread heat on the PCB. In addition to the LT3045 feature set, the LT3045-1 incorporates a VIOC tracking function to control an upstream switching converter to maintain a constant voltage across the LT3045-1 and hence minimize power dissipation. The device supplies 500mA at a typical 260mV dropout voltage. Operating quiescent current is nominally 2.3mA and drops to <1µA in shutdown. The LT3045-1’s wide output voltage range (0V to 15V) while maintaining unity-gain operation provides virtually constant output noise, PSRR, bandwidth and load regulation, independent of the programmed output voltage. Additionally, the regulator features programmable current limit, fast start-up capability and programmable power good to indicate output voltage regulation.
Applications
- RF Power Supplies: PLLs, VCOs, Mixers, LNAs, PAs
- Very Low Noise Instrumentation
- High Speed/High Precision Data Converters
- Medical Applications: Imaging, Diagnostics
- Post-Regulator for Switching Supplies
Key features
- Ultralow RMS Noise: 0.8µV_RMS (10Hz to 100kHz)
- Ultralow Spot Noise: 2nV/√Hz at 10kHz
- Ultrahigh PSRR: 76dB at 1MHz
- Output Current: 500mA
- Wide Input Voltage Range: 1.8V to 20V
- Single Capacitor Improves Noise and PSRR
- 100µA SET Pin Current: ±1% Initial Accuracy
- VIOC Pin Controls Upstream Regulator to Minimize Power Dissipation
- Single Resistor Programs Output Voltage
- Programmable Current Limit
- Low Dropout Voltage: 260mV
- Output Voltage Range: 0V to 15V
- Programmable Power Good
- Fast Start-Up Capability
- Precision Enable/UVLO
- Parallelable for Lower Noise and Higher Current
- Internal Current Limit with Foldback
- Minimum Output Capacitor: 10µF Ceramic
- Reverse-Battery and Reverse-Current Protection
- 12-Lead MSOP and 3mm × 3mm DFN Packages
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | GM1205ACPZ-2-R7#C55067968GONGMOSEMI · DFN-12(3x3) | GONGMOSEMI | DFN-12(3x3) | 139 | ₹588.70 · 139 in stock | View |
 | LT3045EDD-1#PBF#C666575ADI · DFN-12-EP(3x3) | ADI | DFN-12-EP(3x3) | On request | ₹879.00 · 0 in stock | View |
