ST
M24256-DFCS6TP/K
256Kbit 1MHz I2C WLCSP-8(1.3x1.4) Memory RoHS
WLCSP-8(1.3x1.4)ROHS3 CompliantActive
256-Kbit serial I2C bus EEPROM
Datasheet (PDF)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
4,893 in stock
#C221515
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹86.48 | ₹86.48 |
| 10+ | ₹70.20 | ₹702.00 |
| 30+ | ₹62.15 | ₹1,864.50 |
| 100+ | ₹53.90 | ₹5,390.00 |
| 500+ | ₹49.11 | ₹24,555.00 |
| 1,000+ | ₹46.73 | ₹46,730.00 |
1 × ₹86.48
₹86.48
excl. GST
₹102.05 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
M24256-DFCS6TP/K
₹86.48 for 1 + GST
Specifications
- Operating Temperature
- -40℃~+85℃
- Features
- Hardware write protection function;Built-in power-on reset (POR);Built-in error correction code (ECC) function
- Memory Size
- 256Kbit
- Voltage - Supply
- 1.7V~5.5V;2.5mA
- Clock Frequency
- 1MHz
- Data Retention - TDR (Year)
- 200 Years
- Write Cycle Time(tWC)
- 5ms
- Standby Supply Current
- 1uA
- Write Cycle Endurance
- 4,000,000 Cycles
- Interface
- I2C
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.056 g
Overview
The M24256 is a 256-Kbit I²C-compatible EEPROM (Electr
Key features
- Compatible with all I²C bus modes: 1 MHz, 400 kHz, 100 kHz
- Memory array: 256Kbit(32 Kbyte) of EEPROM
- Page size: 64 byte
- Additional Write lockable page (M24256-D order codes)
- Single supply voltage and high speed: 1 MHz clock from 1.7 V to 5.5 V
