onsemiDatasheet (PDF)
MBR1645G
Diode 45V 16A Through Hole TO-220AC-2
TO-220AC-2ROHS3 CompliantActive
DIODE SCHOTTKY 45V TO-220AC-2
- Manufacturer
- onsemi
- Manufacturer part #
- MBR1645G
- Store part #
- C232403
- Package / case
- TO-220AC-2
- Category
- Single Diodes
- Packaging
- Tube-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
111 in stock
#C232403
Stock & price checked 11 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹201.56 | ₹201.56 |
| 10+ | ₹165.72 | ₹1,657.20 |
| 50+ | ₹146.18 | ₹7,309.00 |
| 100+ | ₹123.81 | ₹12,381.00 |
| 500+ | ₹114.03 | ₹57,015.00 |
| 1,000+ | ₹109.47 | ₹1,09,470.00 |
1 × ₹201.56
₹201.56
excl. GST
₹237.84 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 50 per tube
MBR1645G
₹201.56 for 1 + GST
Specifications
- Diode Configuration
- 1 Independent
- Operating Junction Temperature Range
- -65℃~+175℃
- Voltage - DC Reverse (Vr) (Max)
- 45V
- Voltage - Forward(Vf@If)
- 630mV@16A
- Reverse Leakage Current (Ir)
- 200uA@45V
- Non-Repetitive Peak Forward Surge Current
- 150A
- Current - Rectified
- 16A
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tube-packed
- Standard pack
- 50 / Tube
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 2.6 g
Overview
These state- of- the- art devices use the Schottky Barrier principle with a platinum barrier metal.
Key features
- Guard-ring for Stress Protection
- Low Forward Voltage
- 175℃ Operating Junction Temperature
- NRVB Prefix for Automotive and Other Applications Requiring Unique Site and Control Change Requirements; AEC-Q101 Qualified and PPAP Capable
- These Devices are Pb-Free and are RoHS Compliant
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | MBR2045AC#C25836713YFW · TO-220AC | YFW | TO-220AC | 392 | ₹53.13 · 392 in stock | View |
 | VT2045BP-M3/4W#C3757657VISHAY · TO-220AC | VISHAY | TO-220AC | 1 | ₹121.04 · 1 in stock | View |
 | MBR1660#C260267SMC · TO-220-2 | SMC | TO-220-2 | 351 | ₹77.42 · 351 in stock | View |
 | MBRF2045#C260320SMC · TO-220-2 | SMC | TO-220-2 | 19 | ₹65.41 · 19 in stock | View |
 | MBR40250G#C150246onsemi · TO-220AC-2 | onsemi | TO-220AC-2 | 75 | ₹231.30 · 75 in stock | View |
