MC74VHC1G14DTT1G-TP

Schmitt trigger 1.65V~5.5V 4ns@5.5V,50pF 10uA 1 SOT-23-5 Gates and Inverters

SOT-23-5RoHSActive

Manufacturer: TECH PUBLIC
Manufacturer part #: MC74VHC1G14DTT1G-TP
Store part #: C53100490
Package / case: SOT-23-5
Category: Gates and Inverters
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

1,510 in stock

#C53100490

Stock & price checked 6 days ago

Quantity	Unit price	Pack price
10+	₹5.72	₹57.20
100+	₹4.48	₹448.00
300+	₹3.86	₹1,158.00
3,000+	₹3.40	₹10,200.00
6,000+	₹3.03	₹18,180.00
9,000+	₹2.84	₹25,560.00

Quantity (min 10, multiples of 10)

10 × ₹5.72

₹57.20

excl. GST

₹67.50 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 3,000 per reel

MC74VHC1G14DTT1G-TP

₹57.20 for 10 + GST

Specifications

Input Type: Schmitt trigger
Logic Family: 74VHC
Voltage - Supply: 1.65V~5.5V
Propagation Delay: 4ns@5.5V,50pF
Output Logic Level - Low: 100mV
Features: Power shutdown protection;Noise suppression function
Operating Temperature: -40℃~+125℃
Output Logic Level - High: 1.2V;1.9V;2.2V;2.3V;3.8V
Quiescent Current(Iq): 10uA
Number of Channels: 1

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 10 (multiples of 10)
Unit weight: 0.1 g

Overview

MC74VHC1G14 is a single Schmitt-trigger inverter with the function Y = A. Due to the Schmitt-trigger action at the input, the device has different input threshold levels for positive-going signals (VT+) and negative-going signals (VT−).

Applications

Audio/Video Receivers
Audio Docking Stations
Blu-ray Players & Home Theater Systems
Embedded PCs
Personal Digital Assistants

Key features

Operating voltage range: 1.65V ~ 5.5V
Power-down protection
Output drive current: ±24mA (at VCC=3.0V)
Low power consumption, maximum quiescent current 10μA
ESD protection exceeds JESD 22 standard: HBM 2000V (A114-A), MM 200V (A115-A), CDM 1000V (C101)
