MS1651
40V/us 1 10.5MHz 6 SOT-23-6 Video Amps and Modules RoHS
SOT-23-6ROHS CompliantActive
Single-channel 6th-order standard-definition video filtering driver
- Manufacturer
- Hangzhou Ruimeng Tech
- Manufacturer part #
- MS1651
- Store part #
- C231919
- Package / case
- SOT-23-6
- Category
- Video Amps and Modules
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
17,440 in stock
#C231919
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹8.69 | ₹86.90 |
| 100+ | ₹6.83 | ₹683.00 |
| 300+ | ₹5.89 | ₹1,767.00 |
| 3,000+ | ₹5.19 | ₹15,570.00 |
| 6,000+ | ₹4.62 | ₹27,720.00 |
| 9,000+ | ₹4.34 | ₹39,060.00 |
10 × ₹8.69
₹86.90
excl. GST
₹102.54 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
MS1651
₹86.90 for 10 + GST
Specifications
- Differential Phase
- 0.3deg
- Single Supply
- 2.5V~5.5V
- Differential Gain
- 0.02%
- Features
- Input buffer;Anti-aliasing / reconstruction filter;Enable/shutdown function
- Operating Temperature
- -40℃~+125℃
- Slew Rate
- 40V/us
- Number of Channels
- 1
- -3dB Bandwidth
- 10.5MHz
- Filter Order
- 6
- Quiescent Current
- 6mA
- Output Current
- 115mA
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.041 g
Overview
The MS1651 is a single-channel video buffer integrating a rail-to-rail output driver with 6dB gain and a 6th-order output reconstruction filter. It features a -3dB bandwidth of 10.5MHz and a slew rate of 40V/μs, delivering superior image quality compared to passive LC filter solutions with external drivers. Operating from a single supply ranging from +2.5V to +5.5V with an extremely low quiescent current of 14.5mA, it is ideally suited for battery-powered applications. The input signal is the DAC output, supporting either DC-coupled or AC-coupled input. Internal diode clamping and biasing circuits are available for AC-coupled input configurations. An internal level-shifting circuit prevents sync pulse clipping and allows DC-coupled output. The output can drive DC- or AC-coupled single (150Ω) or dual (75Ω) loads. Housed in a SOT23-6 6-pin package with 8kV ESD protection. The MS1651 operates from a single supply of +2.5V to +5V, serving as a complete filter and buffer solution for standard-definition video signal decoding and encoding. Compared to conventional discrete-component designs, this solution reduces PCB area, lowers cost, and improves video signal performance. It integrates a DC-coupled input buffer, a video encoder that eliminates out-of-band noise, and an op-amp driver with +6dB gain capable of driving 75Ω loads. The AC- or DC-coupled input buffer eliminates sync compression, bowing, and field tilt. The output can also be DC-coupled or AC-coupled.
Applications
- Video amplifiers
- Cable TV and satellite set-top boxes
- Communications equipment
- Consumer video
- Portable and handheld products
- Personal video recorders
- DVD players
- Standard-definition TV
- Projectors and slide projectors
Key features
- Single-channel 6th-order 10.5MHz filter
- Transparent input clamp
- 6dB gain output driver with dual video load drive capability
- Rail-to-rail output
- Input voltage range includes ground
- AC or DC coupled input
- AC or DC coupled output
- Single-supply operating range: 2.5V to 5.5V
- Low power consumption, operating current 14.5mA
- SOT23-6 package
