MSKSEMIDatasheet (PDF)
MS3608
1.2MHz Boost Adjustable 600mV~28V SOT-23-6 Voltage Regulators - DC DC Switching Regulators
SOT-23-6RoHSActive
- Manufacturer
- MSKSEMI
- Manufacturer part #
- MS3608
- Store part #
- C49208386
- Package / case
- SOT-23-6
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,480 in stock
#C49208386
Stock & price checked 29 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹15.70 | ₹78.50 |
| 50+ | ₹12.48 | ₹624.00 |
| 150+ | ₹10.86 | ₹1,629.00 |
| 500+ | ₹9.64 | ₹4,820.00 |
| 3,000+ | ₹8.68 | ₹26,040.00 |
| 6,000+ | ₹8.19 | ₹49,140.00 |
5 × ₹15.70
₹78.50
excl. GST
₹92.63 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
MS3608
₹78.50 for 5 + GST
Specifications
- Operating Temperature
- -40℃~+85℃
- Frequency - Switching
- 1.2MHz
- Function
- Boost
- Number of Outputs
- 1
- Features
- Light load efficient mode;Overcurrent Protection
- Output Type
- Adjustable
- Topology
- Boost
- Operating Voltage
- 2.5V~24V
- Switch tube (built-in/external)
- Built-in
- Output Voltage
- 600mV~28V
- Quiescent Current
- 70uA
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Moisture sensitivity
- MSL 3 (168 hours)
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.045 g
Overview
This device is a constant-frequency, 6-pin SOT-23 current-mode boost converter designed for small, low-power applications. Its switching frequency of 1.2MHz allows the use of miniature, low-cost capacitors and inductors with heights of 2mm or less. Internal soft-start reduces inrush current and extends battery life. The device features automatic switchover to pulse frequency modulation mode under light-load conditions. It includes undervoltage lockout, current limiting, and thermal overload protection to prevent damage during output overload. The device is available in a compact 6-pin SOT-23 package.
Applications
- Battery-powered devices
- Set-top boxes
- LCD bias power supplies
- DSL and cable modems and routers
- Network cards powered from PCI or PCI Express slots
Key features
- Integrated 80mΩ power MOSFET
- 2.5V to 24V input voltage range
- 1.2MHz fixed switching frequency
- Internal 4A switch current limit
- Adjustable output voltage
- Internal compensation
- Output voltage up to 28V
- Automatic pulse frequency modulation mode at light load
- Up to 93% efficiency
- 6-pin SOT23-6 package
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | MSTLV61048DBVR#C49208387MSKSEMI · SOT-23-6 | MSKSEMI | SOT-23-6 | 2,945 | ₹20.44 · 2,945 in stock | View |
