MSKSEMIDatasheet (PDF)
MSTPS563200DDCR
Step-down type 600kHz Adjustable 3A 800mV~6V SOT-23-6 Voltage Regulators - DC DC Switching Regulators
SOT-23-6RoHSActive
- Manufacturer
- MSKSEMI
- Manufacturer part #
- MSTPS563200DDCR
- Store part #
- C49208508
- Package / case
- SOT-23-6
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
3,205 in stock
#C49208508
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹22.41 | ₹112.05 |
| 50+ | ₹17.70 | ₹885.00 |
| 150+ | ₹15.69 | ₹2,353.50 |
| 500+ | ₹13.18 | ₹6,590.00 |
| 3,000+ | ₹12.05 | ₹36,150.00 |
| 6,000+ | ₹11.38 | ₹68,280.00 |
5 × ₹22.41
₹112.05
excl. GST
₹132.22 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
MSTPS563200DDCR
₹112.05 for 5 + GST
Specifications
- Operating Temperature
- -40℃~+85℃
- Number of Outputs
- 1
- Function
- Step-down type
- Frequency - Switching
- 600kHz
- Features
- Cycle-by-cycle current limiting;Hiccup current limiting;Light load efficient mode;Adjustable soft-start;Overcurrent Protection
- Output Type
- Adjustable
- Topology
- Buck
- Operating Voltage
- 4V~16V
- Switch tube (built-in/external)
- Built-in
- Output Current
- 3A
- Output Voltage
- 800mV~6V
- Quiescent Current
- 600uA
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.043 g
Overview
The MSTPS563200DDCR is a synchronous buck converter utilizing fixed on-time (COT) control technology. Its main control loop operates in COT mode, supporting low-ESR ceramic capacitors and enabling fast transient response without external compensation components. At a 1.2V output voltage, the output voltage deviation is only 50mV during 0 to 3A load transients. This technology enables seamless transition between heavy-load PWM mode and light-load operating mode, maintaining high efficiency under light-load conditions. The device operates over an input voltage range of 4.0V to 16V, with an adjustable output voltage from 0.8V to 6V. Additionally, soft-start time is adjustable, and the device integrates over-temperature protection, under-voltage protection, and cycle-by-cycle current limiting.
Applications
- Digital TV
- Home network terminal
- Digital set-top box
- DSL modem
Key features
- COT operating mode
- Ultra-fast transient response
- Compatible with low-ESR ceramic capacitors
- Low output ripple
- Reference voltage: 0.8V
- Output voltage range: 0.8V to 6V
- 3A output current
- 600KHz pseudo-fixed frequency (at 5V output)
- Light-load mode switching
- Input voltage range: 4.0V to 16V
- Internal soft-start
- Cycle-by-cycle valley current limiting
- Integrated internal compensation
- TSOT23-6 package
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | MSTPS563201DDCR#C49208507MSKSEMI · SOT-23-6 | MSKSEMI | SOT-23-6 | 5,500 | ₹14.69 · 5,500 in stock | View |
