Wuxi Maxinmicro

MX2205HLC

SOT-23-6 Power Management - Specialized RoHS

SOT-23-6ROHS CompliantActive

5V low-power mechanical push-button toggle switch

Manufacturer: Wuxi Maxinmicro
Manufacturer part #: MX2205HLC
Store part #: C49075725
Package / case: SOT-23-6
Category: Power Management - Specialized
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

2,545 in stock

#C49075725

Stock & price checked 40 h ago

Quantity	Unit price	Pack price
5+	₹12.37	₹61.85
50+	₹9.78	₹489.00
150+	₹8.48	₹1,272.00
500+	₹7.51	₹3,755.00
3,000+	₹6.73	₹20,190.00
6,000+	₹6.35	₹38,100.00

Quantity (min 5, multiples of 5)

5 × ₹12.37

₹61.85

excl. GST

₹72.98 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 3,000 per reel

MX2205HLC

₹61.85 for 5 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Operating Temperature: -10℃~+65℃
Voltage - Supply: 2.2V~5.5V

Packaging & compliance

RoHS: ROHS Compliant
Lifecycle: Active
Moisture sensitivity: MSL 3 (168 hours)
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.046 g

Overview

The switch control IC operates at a supply voltage range of DC 2.2–5.0V, controlled via a tactile button KEY, and manages 2 output channels: OUTH and OUTL. Upon power-up, OUTH is low and OUTL is high. After pressing and holding the button for 5 seconds, OUTH goes high and OUTL goes low. Pressing and holding again for 5 seconds reverses the output levels.
