NCV8450ASTT3G
1 Active Low High Side Switch SOT-223 Power Distribution Switches, Load Drivers RoHS
SOT-223ROHS CompliantActive
Self-Protected High Side Driver with Temperature and Current Limit
- Manufacturer
- onsemi
- Manufacturer part #
- NCV8450ASTT3G
- Store part #
- C100028
- Package / case
- SOT-223
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,994 in stock
#C100028
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹130.36 | ₹130.36 |
| 10+ | ₹104.50 | ₹1,045.00 |
| 30+ | ₹91.47 | ₹2,744.10 |
| 100+ | ₹78.65 | ₹7,865.00 |
| 500+ | ₹71.05 | ₹35,525.00 |
| 1,000+ | ₹67.14 | ₹67,140.00 |
1 × ₹130.36
₹130.36
excl. GST
₹153.82 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 4,000 per reel
NCV8450ASTT3G
₹130.36 for 1 + GST
Specifications
- Operating Temperature
- -40℃~+150℃
- Features
- Overcurrent Protection;Short-Circuit Protection;Over temperature protection;Overvoltage protection;Load dump protection
- number of channels
- 1
- Control Input Logic
- Active Low
- Operating Voltage
- 4.5V~45V
- RDS(on)
- 1Ω
- Type
- High Side Switch
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 4,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.205 g
Overview
The NCV8450/A is a fully protected High- Side Smart Discrete device with a typical RDS(on) of 1.0Ω and an internal current limit of 0.8A typical. The device can switch a wide variety of resistive, inductive, and capacitive loads.
Applications
- Automotive
- Industrial
Key features
- Short Circuit Protection
- Thermal Shutdown with Automatic Restart
- Overvoltage Protection
- Integrated Clamp for Inductive Switching
- Loss of Ground Protection
- ESD Protection
- Slew Rate Control for Low EMI
- Very Low Standby Current
- NCV Prefix for Automotive and Other Applications Requiring Unique Site and Control Change Requirements; AEC - Q100 Qualified and PPAP Capable
- These Devices are Pb - Free, Halogen Free/BFR Free and are RoHS Compliant
