NTMFS6H818NLT1G
140W 80V 135A 2.7mΩ@10V 1 N-channel N-Channel DFN-5(5.9x4.9) Single FETs, MOSFETs RoHS
DFN-5(5.9x4.9)ROHS3 CompliantActive
MOSFET N-CH 80V 135A DFN-5(5.9x4.9)
- Manufacturer
- onsemi
- Manufacturer part #
- NTMFS6H818NLT1G
- Store part #
- C900317
- Package / case
- DFN-5(5.9x4.9)
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
20 in stock
#C900317
Stock & price checked 3 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹362.95 | ₹362.95 |
| 10+ | ₹357.32 | ₹3,573.20 |
| 30+ | ₹353.41 | ₹10,602.30 |
| 100+ | ₹349.51 | ₹34,951.00 |
1 × ₹362.95
₹362.95
excl. GST
₹428.28 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 1,500 per reel
NTMFS6H818NLT1G
₹362.95 for 1 + GST
Specifications
- Output Capacitance(Coss)
- 484pF
- Ciss-Input Capacitance
- 3.844nF
- Pd - Power Dissipation
- 140W
- Operating Temperature
- -55℃~+175℃
- Drain to Source Voltage
- 80V
- Current - Continuous Drain(Id)
- 135A
- Reverse Transfer Capacitance (Crss)
- 21pF
- RDS(on)
- 2.7mΩ@10V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 64nC@10V
- Vgs
- ±20V
- Gate Threshold Voltage (Vgs(th))
- 2V
- Type
- N-Channel
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 1,500 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.494 g
Overview
Key features
- Compact package (5x6 mm) for space-constrained designs
- Low on-resistance RDS(on) minimizes conduction losses
- Low gate charge QG and capacitance minimize driving losses
- Lead-free, RoHS compliant
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | NVMFS6H801NT1G#C604623onsemi · DFN-5(5.9x4.9) | onsemi | DFN-5(5.9x4.9) | 41 | ₹426.85 · 41 in stock | View |
 | NVMFS6H800NWFT1G#C604622onsemi · DFN-5(5.9x4.9) | onsemi | DFN-5(5.9x4.9) | 20 | ₹964.37 · 20 in stock | View |
 | NVMFS6H801NLT1G#C900465onsemi · DFN-5(5.9x4.9) | onsemi | DFN-5(5.9x4.9) | 20 | ₹506.64 · 20 in stock | View |
 | NVMFS6H818NWFT1G#C900469onsemi · DFN-5(5.9x4.9) | onsemi | DFN-5(5.9x4.9) | 4 | ₹415.26 · 4 in stock | View |
 | NVMFS6H800NLWFT1G#C900464onsemi · DFN-5(5.9x4.9) | onsemi | DFN-5(5.9x4.9) | 101 | ₹947.43 · 101 in stock | View |
