PN8015SSC-R1D
200mA 820V 3.3V~24V SOP-7 AC DC Converters, Offline Switchers RoHS
SOP-7ROHS CompliantActive
Wide output range non-isolated AC-DC conversion chip
- Manufacturer
- Wuxi Chipown Micro-electronics
- Manufacturer part #
- PN8015SSC-R1D
- Store part #
- C2984670
- Package / case
- SOP-7
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
3,450 in stock
#C2984670
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹39.20 | ₹196.00 |
| 50+ | ₹30.77 | ₹1,538.50 |
| 150+ | ₹27.16 | ₹4,074.00 |
| 500+ | ₹22.66 | ₹11,330.00 |
| 2,500+ | ₹20.65 | ₹51,625.00 |
| 4,000+ | ₹19.45 | ₹77,800.00 |
5 × ₹39.20
₹196.00
excl. GST
₹231.28 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 4,000 per reel
PN8015SSC-R1D
₹196.00 for 5 + GST
Specifications
- Operating Temperature
- -40℃~+150℃
- Output Current
- 200mA
- Voltage - Breakdown
- 820V
- Features
- High voltage direct start;Leading edge blanking;Under-voltage lockout;EMI optimization (spread spectrum);Overtemperature protection (OTP);Overload Protection;Under Voltage Protection
- Topology
- Buck;Buck-Boost;Flyback
- Output Voltage
- 3.3V~24V
- Working Mode
- CCM;DCM
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 4,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.2 g
Overview
The PN8015 integrates a PFM controller and an 800V high-avalanche-capability smart power MOSFET, designed for low-power non-isolated switching power supplies with minimal peripheral components, with output voltage adjustable via FB resistors. The PN8015 incorporates a high-voltage startup and self-supply module, enabling fast system startup, ultra-low standby power, and self-powering capability. The device offers comprehensive intelligent protection features, including overload protection, undervoltage protection, and over-temperature protection. Additionally, the PN8015's frequency-reduction modulation technique helps improve EMI performance.
Applications
- Non-isolated auxiliary power supply
- Home appliances
- Smart home
- LED
Key features
- Integrated 800V high-avalanche-capability intelligent power MOSFET
- Integrated high-voltage startup and self-supply circuit
- Compatible with Buck, Buck-Boost, Flyback, and other topologies
- Output voltage 3.3V~24V adjustable via FB resistor
- Semi-closed-loop steady-state output current 200mA @230VAC, 5V output
- Frequency-reduction modulation for improved EMI
- Excellent load regulation and efficiency
- Comprehensive protection features
- Overload Protection (OLP)
- Over-Temperature Protection (OTP)
- Under-Voltage Lockout (UVLO)
