YAGEODatasheet (PDF)
RL2010FK-070R075L
75mΩ 750mW Thick Film Resistor ±1000ppm/℃ ±1% 2010 Chip Resistor - Surface Mount RoHS
2010ROHS3 CompliantActive
RES 0.075Ω ±1% 750mW 2010
- Manufacturer
- YAGEO
- Manufacturer part #
- RL2010FK-070R075L
- Store part #
- C876380
- Package / case
- 2010
- Category
- Chip Resistor - Surface Mount
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
460 in stock
#C876380
Stock & price checked 12 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹6.88 | ₹68.80 |
| 100+ | ₹5.53 | ₹553.00 |
| 300+ | ₹4.86 | ₹1,458.00 |
| 1,000+ | ₹4.34 | ₹4,340.00 |
| 4,000+ | ₹3.93 | ₹15,720.00 |
| 8,000+ | ₹3.73 | ₹29,840.00 |
10 × ₹6.88
₹68.80
excl. GST
₹81.18 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 4,000 per reel
RL2010FK-070R075L
₹68.80 for 10 + GST
Specifications
- Resistance
- 75mΩ
- Power(Watts)
- 750mW
- Type
- Thick Film Resistor
- Temperature Coefficient
- ±1000ppm/℃
- Tolerance
- ±1%
- Operating Temperature
- -55℃~+155℃
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 4,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.046 g
Overview
This specification describes low-ohm chip resistors from RL0402 to RL2512, manufactured using thick-film technology with lead-free terminations.
Applications
- Converters, printer devices, server boards, telecommunications, consumer electronics, automotive electronics
Key features
- AEC-Q200 qualified
- Halogen-free epoxy
- RoHS compliant
- No hazardous waste
- High component and device reliability
- PCB space saving
- Non-prohibited materials used in product/production
- Low resistance for current sensing
- MSL rating: MSL I
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | FRL2010FR075TS#C5204050FOJAN · 2010 | FOJAN | 2010 | 3,340 | ₹5.27 · 3,340 in stock | View |
 | 201007F750MT4E#C421779UNI-ROYAL · 2010 | UNI-ROYAL | 2010 | On request | ₹6.77 · 0 in stock | View |
 | RTT20R075FTE#C333474RALEC · 2010 | RALEC | 2010 | On request | ₹6.10 · 0 in stock | View |
| RLC73N2HR075FTDF#C20425239TE Connectivity · 2010 | TE Connectivity | 2010 | On request | ₹18.79 · 0 in stock | View | |
| RLC73N2HR075FTE#C20425363TE Connectivity · 2010 | TE Connectivity | 2010 | On request | ₹15.77 · 0 in stock | View | |
