onsemiDatasheet (PDF)
RS1MFA
500ns 1 Independent 1kV 1.3V@800mA 800mA SOD-123 FL Single Diodes RoHS
SOD-123 FLROHS3 CompliantActive
Diode 1kV 800mA SOD-123 FL
- Manufacturer
- onsemi
- Manufacturer part #
- RS1MFA
- Store part #
- C894222
- Package / case
- SOD-123 FL
- Category
- Single Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
85 in stock
#C894222
Stock & price checked 8 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹40.10 | ₹200.50 |
| 50+ | ₹32.20 | ₹1,610.00 |
| 150+ | ₹28.83 | ₹4,324.50 |
| 500+ | ₹24.61 | ₹12,305.00 |
| 3,000+ | ₹20.92 | ₹62,760.00 |
| 6,000+ | ₹19.78 | ₹1,18,680.00 |
5 × ₹40.10
₹200.50
excl. GST
₹236.59 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
RS1MFA
₹200.50 for 5 + GST
Specifications
- Reverse Recovery Time (trr)
- 500ns
- Diode Configuration
- 1 Independent
- Operating Junction Temperature Range
- -55℃~+150℃
- Voltage - DC Reverse (Vr) (Max)
- 1kV
- Voltage - Forward(Vf@If)
- 1.3V@800mA
- Reverse Leakage Current (Ir)
- 5uA@1kV
- Non-Repetitive Peak Forward Surge Current
- 30A
- Current - Rectified
- 800mA
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.05 g
Overview
Key features
- Glass Passivated Chip Junction
- Fast Switching for High Efficiency
- High Surge Capacity
- Low Forward Voltage: 1.3 V Maximum
- UL Flammability 94V−0 Classification
- MSL 1 per J−STD−020
- RoHS Compliant / Green Molding Compound
- Industrial Device Qualified per AEC−Q101 Standards
- NRVHP Prefix for Automotive and Other Applications Requiring Unique Site and Control Change Requirements; AEC−Q101 Qualified and PPAP Capable
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | FR107W#C108820Jingdao Microelectronics · SOD-123F | Jingdao Microelectronics | SOD-123F | 1,24,650 | ₹1.22 · 1,24,650 in stock | View |
 | FR107W#C1884541YFW · SOD-123FL | YFW | SOD-123FL | 8,720 | ₹1.48 · 8,720 in stock | View |
 | RS07M#C19267703JSCJ · SOD-123FL | JSCJ | SOD-123FL | 8,850 | ₹2.57 · 8,850 in stock | View |
 | F1M#C20624198YFW · SOD-123FL | YFW | SOD-123FL | 250 | ₹1.59 · 250 in stock | View |
 | F7#C22368825Wild Goose · SOD-123FL | Wild Goose | SOD-123FL | 11,600 | ₹0.7276 · 11,600 in stock | View |
