KOADatasheet (PDF)
RS73F2BTTD5104B
333mW 5.1MΩ Thick Film Resistor ±25ppm/℃ ±0.1% 1206 Chip Resistor - Surface Mount RoHS
1206ROHS3 CompliantActive
RES 5.1MΩ ±0.1% 0.333W 1206
- Manufacturer
- KOA
- Manufacturer part #
- RS73F2BTTD5104B
- Store part #
- C20098211
- Package / case
- 1206
- Category
- Chip Resistor - Surface Mount
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
3,655 in stock
#C20098211
Stock & price checked 27 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹46.66 | ₹233.30 |
| 50+ | ₹36.87 | ₹1,843.50 |
| 150+ | ₹32.68 | ₹4,902.00 |
| 500+ | ₹27.44 | ₹13,720.00 |
| 2,500+ | ₹25.11 | ₹62,775.00 |
| 5,000+ | ₹23.71 | ₹1,18,550.00 |
5 × ₹46.66
₹233.30
excl. GST
₹275.29 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 5,000 per reel
RS73F2BTTD5104B
₹233.30 for 5 + GST
Specifications
- Power(Watts)
- 333mW
- Resistance
- 5.1MΩ
- Type
- Thick Film Resistor
- Temperature Coefficient
- ±25ppm/℃
- Tolerance
- ±0.1%
- Operating Temperature
- -55℃~+155℃
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 5,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.029 g
Overview
Key features
- Metal glaze thick film resistor for SMT
- High-precision resistor with temperature coefficient ±25×10⁻⁶/K and tolerance ±0.1%
- High reliability with ΔR of ±0.2% and ±0.5% in reliability testing
- Compatible with wave soldering and reflow soldering
- Lead-free termination compliant with EU RoHS. EU RoHS directive does not apply to lead glass contained in electrodes, resistive elements, and glass
- AEC-Q200 qualified
