RICHTEK

RT1715WSC

Transceiver 300Kbps CSP-9(1.38x1.34) Controllers RoHS

CSP-9(1.38x1.34)ROHS3 CompliantActive

Programmable USB Type-C PD Controller

Manufacturer: RICHTEK
Manufacturer part #: RT1715WSC
Store part #: C2976586
Package / case: CSP-9(1.38x1.34)
Category: Controllers
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

12,135 in stock

#C2976586

Stock & price checked 6 days ago

Quantity	Unit price	Pack price
5+	₹52.14	₹260.70
50+	₹41.56	₹2,078.00
150+	₹37.02	₹5,553.00
500+	₹31.36	₹15,680.00
3,000+	₹28.83	₹86,490.00
6,000+	₹27.32	₹1,63,920.00

Quantity (min 5, multiples of 5)

5 × ₹52.14

₹260.70

excl. GST

₹307.63 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 3,000 per reel

RT1715WSC

₹260.70 for 5 + GST

Specifications

Features: Low-power mode;Shutdown mode
Voltage - Supply: 2.7V~5.5V
Operating Temperature: -40℃~+85℃
Applications Function: Transceiver
Quiescent Supply Current: 25uA
Data Rate: 300Kbps

Packaging & compliance

RoHS: ROHS3 Compliant
Lifecycle: Active
ECCN: EAR99
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.028 g

Overview

The RT1715 is a USB Type-C controller that complies with the latest USB Type-C and PD standards. The RT1715 integrates a complete Type-C Transceiver including the Rp and Rd resistors. It does the USB Type-C detection including attach and orientation. The RT1715 integrates the physical layer of the USB BMC power delivery protocol to allow up to 100W of power and role swap. The BMC PD block enables full support for alternative interfaces of the Type-C specification.
